DETAILED COOLING CAPACITIES* Continued
See notes on page 25.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
597CN042-F, G Outdoor Section With CC5A/CD5BAA042 Indoor Section
1225
72 45.8 22.5 3.47 44.1 21.8 3.83 42.3 21.2 4.22 40.5 20.5 4.6 38.7 19.8 5.13
67 41.8 28.3 3.44 40.2 27.6 3.78 38.6 27.0 4.17 36.9 26.3 4.6 35.2 25.6 5.07
62 38.0 33.9 3.40 36.6 33.2 3.74 35.1 32.5 4.13 33.6 31.7 4.5 32.1 30.9 5.02
57 36.2 36.2 3.38 35.1 35.1 3.73 33.9 33.9 4.12 32.7 32.7 4.5 31.5 31.5 5.01
1400
72 46.6 23.5 3.55 44.9 22.8 3.91 43.0 22.1 4.29 41.2 21.5 4.7 39.3 20.8 5.21
67 42.6 30.0 3.52 41.0 29.3 3.87 39.3 28.7 4.25 37.5 27.9 4.6 35.8 27.2 5.15
62 38.8 36.2 3.48 37.4 35.4 3.83 35.8 34.5 4.20 34.3 33.6 4.6 32.8 32.6 5.10
57 37.6 37.6 3.46 36.4 36.4 3.81 35.2 35.2 4.20 33.9 33.9 4.6 32.6 32.6 5.11
1575
72 47.3 24.4 3.62 45.5 23.7 3.98 43.6 23.1 4.37 41.6 22.4 4.8 39.6 21.7 5.28
67 43.3 31.6 3.59 41.5 31.0 3.94 39.8 30.3 4.32 38.0 29.5 4.7 36.2 28.8 5.22
62 39.5 38.2 3.56 38.0 37.2 3.90 36.5 36.2 4.28 35.0 35.0 4.7 33.6 33.6 5.19
57 38.9 38.9 3.55 37.6 37.6 3.89 36.3 36.3 4.28 34.9 34.9 4.7 33.6 33.6 5.19
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 042 1.00 1.00
COILS + 315(A,J)AV066110 VARIABLE SPEED FURNACE
CC5A/CD5AC 048 0.99 1.00 CC5A/CD5AA 042 0.98 0.91
CC5A/CD5AW 042 1.00 1.00 CC5A/CD5AC 048 0.96 0.90
048 1.00 1.00 CC5A/CD5AW 042 0.98 0.92
CD5AA 048 1.00 1.00 048 0.99 0.91
CE3AA 042 1.00 1.00 CD5AA 048 0.99 0.91
048 1.01 1.00 CE3AA 042 0.98 0.91
CF5AA 048 1.01 1.00 048 0.99 0.91
CK3BA 042 1.00 1.00 CK3BA 042 0.98 0.91
048 1.00 1.00 048 0.99 0.91
CK5A/CK5BA 042 1.00 1.00 CK5A/CK5BA 042 0.98 0.91
048 1.00 1.00 048 0.99 0.91
CK5A/CK5BN 042 0.98 1.00 CK5A/CK5BT 042 0.98 0.91
048 0.98 1.00 048 0.99 0.91
CK5A/CK5BW 048 1.00 1.00 CK5A/CK5BW 048 0.99 0.91
F(A,B)4(A,B)N(F,B) 042 1.00 1.01
COILS + 315(A,J)AV066135 VARIABLE SPEED FURNACE
048 1.01 1.02 CC5A/CD5AA 042 0.98 0.91
FC4(B,C)N(F,B) 042 1.00 1.01 CC5A/CD5AC 048 0.96 0.90
048 1.01 1.02 CC5A/CD5AW 042 0.98 0.92
FC4(B,C)NF 038 1.02 1.02 048 0.99 0.91
FC4(B,C)NB 054 1.05 1.00 CD5AA 048 0.99 0.91
FG3AAA 048 1.00 1.00 CE3AA 042 0.98 0.91
FK4(C,D)NB 005 1.02 0.96 048 0.99 0.91
006 1.05 0.94 CK3BA 042 0.98 0.91
FK4(C,D)NF 003 1.01 0.95 048 0.99 0.91
005 1.02 0.96 CK5A/CK5BA 042 0.98 0.91
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE 048 0.99 0.91
CC5A/CD5AA 042 0.98 0.92 CK5A/CK5BT 042 0.98 0.91
CC5A/CD5AC 048 0.96 0.91 048 0.99 0.91
CD5AA 048 0.99 0.92 CK5A/CK5BW 048 0.99 0.91
CE3AA 042 0.98 0.92
COILS + 315(A,J)AV066155 VARIABLE SPEED FURNACE
048 0.99 0.92 CC5A/CD5AA 042 0.98 0.91
CK3BA 042 0.98 0.92 CC5A/CD5AC 048 0.96 0.90
048 0.99 0.92 CC5A/CD5AW 042 0.98 0.92
CK5A/CK5BA 042 0.98 0.92 048 0.99 0.91
048 0.99 0.92 CD5AA 048 0.99 0.91
CK5A/CK5BE 042 0.98 0.91 CE3AA 042 0.98 0.90
CK5A/CK5BT 042 0.98 0.92 048 0.99 0.91
048 0.99 0.92 —— —
