DETAILED COOLING CAPACITIES* Continued
See notes on page 25.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**
Capacity
MBtuh†
Total
System
kW**Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
597CN030-F, G Outdoor Section With CC5A/CD5AA030 Indoor Section
875
72 32.3 15.8 2.37 31.0 15.3 2.68 29.8 14.8 3.04 28.4 14.3 3.4 27.0 13.8 3.86
67 29.6 19.8 2.39 28.5 19.4 2.71 27.3 18.9 3.07 26.0 18.3 3.4 24.6 17.8 3.86
62 27.0 23.8 2.41 25.9 23.3 2.73 24.8 22.8 3.09 23.7 22.2 3.4 22.4 21.5 3.86
57 25.6 25.6 2.43 24.8 24.8 2.75 23.9 23.9 3.09 22.9 22.9 3.4 22.0 22.0 3.88
1000
72 32.8 16.4 2.40 31.6 15.9 2.72 30.3 15.5 3.08 28.9 15.0 3.4 27.4 14.4 3.92
67 30.1 21.0 2.44 29.0 20.5 2.76 27.7 20.0 3.10 26.4 19.5 3.4 25.0 18.9 3.92
62 27.5 25.4 2.46 26.5 24.8 2.78 25.3 24.2 3.14 24.1 23.5 3.5 22.9 22.7 3.91
57 26.5 26.5 2.46 25.7 25.7 2.78 24.8 24.8 3.13 23.8 23.8 3.5 22.8 22.8 3.93
1125
72 33.3 17.0 2.44 32.0 16.6 2.77 30.7 16.1 3.13 29.2 15.6 3.5 27.6 15.0 3.94
67 30.6 22.1 2.48 29.3 21.6 2.79 28.1 21.1 3.15 26.7 20.5 3.5 25.3 20.0 3.97
62 28.0 26.7 2.50 26.9 26.1 2.83 25.7 25.4 3.17 24.5 24.5 3.5 23.4 23.4 3.97
57 27.4 27.4 2.50 26.4 26.4 2.81 25.5 25.5 3.17 24.5 24.5 3.5 23.4 23.4 3.98
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 030 1.00 1.00 CE3AA 030 0.99 0.90
036 1.02 1.00 036 1.00 0.90
CC5A/CD5AW 030 1.00 1.00 CK3BA 030 0.99 0.91
CD5AW 036 1.02 1.00 036 1.00 0.89
CE3AA 030 1.00 1.00 CK5A/CK5BA 030 0.99 0.91
036 1.02 1.00 036 1.00 0.89
CF5AA 036 1.02 1.00 CK5A/CK5BW 030 0.99 0.91
CK3BA 030 1.00 1.00 036 1.00 0.89
036 1.02 1.00
COILS + 355MAV042040 VARIABLE SPEED FURNACE
CK5A/CK5BA 030 1.00 1.00 CC5A/CD5AA 030 1.02 0.94
036 1.02 1.00 036 1.03 0.93
CK5A/CK5BN 036 0.95 1.00 CK3BA 030 1.00 0.96
CK5A/CK5BW 030 1.00 1.00 036 1.02 0.95
036 1.02 1.00 CK5A/CK5BW 030 1.00 0.96
F(A,B)4(A,B)NF 030 1.01 0.99 036 1.02 0.95
036 1.02 1.01
COILS + 355MAV042060 VARIABLE SPEED FURNACE
FC4(B,C)NF 030 1.01 0.99 CC5A/CD5AA 030 1.02 0.94
036 1.02 1.01 036 1.03 0.93
FF1DNA 030 1.02 1.00 CK3BA 030 1.00 0.96
FG3AAA 036 1.01 1.00 036 1.02 0.95
FK4(C,D)NF 001 1.02 0.96 CK5A/CK5BA 036 1.02 0.95
002 1.02 0.96 CK5A/CK5BW 030 1.00 0.96
003 1.03 0.92
COILS + 355MAV042080 VARIABLE SPEED FURNACE
004 1.04 0.93 CC5A/CD5AA 030 1.02 0.94
COILS + 315(A,J)AV036070 VARIABLE SPEED FURNACE 036 1.03 0.93
CC5A/CD5AA 030 0.99 0.92 CK3BA 030 1.00 0.96
036 1.00 0.90 036 1.02 0.94
CC5A/CD5AW 030 0.99 0.92 CK5A/CK5BW 030 1.00 0.96
CE3AA 030 0.99 0.91 036 1.02 0.94
036 1.00 0.92
COILS + 355MAV060080 VARIABLE SPEED FURNACE
CK3BA 030 0.99 0.92 CK3BA 030 1.00 0.97
036 1.00 0.90 036 1.02 0.95
CK5A/CK5BA 030 0.99 0.92 CK5A/CK5BW 030 1.00 0.97
036 1.00 0.90 036 1.02 0.95
CK5A/CK5BT 036 1.00 0.90
COILS + 355MAV060100 VARIABLE SPEED FURNACE
CK5A/CK5BW 030 0.99 0.92 CK5A/CK5BW 030 1.00 0.94
COILS + 315(A,J)AV048090 VARIABLE SPEED FURNACE 036 1.02 0.93
CC5A/CD5AA 030 0.99 0.91 CK3BA 030 1.00 0.94
036 1.00 0.89 036 1.02 0.93
CC5A/CD5AW 030 0.99 0.91
COILS + 355MAV060120 VARIABLE SPEED FURNACE
036 1.00 0.89 CK3BA 030 1.00 0.94
—— — 036 1.02 0.93
CK5A/CK5BW 036 1.02 0.93
