SG-619AHB-01: Service Manual
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
3
SPECIFICATIONS
Table 2 — Specifications
Performance may vary based on the matched outdoor unit. See Table 3 for compatible outdoor units.
Legend
MCA-Minimum Circuit Amps
COMPATIBILITY
Table 3 — Compatibility
System
Size 12 6 9 12 18 24 30 36
Indoor Model 619AHBQ12XA1 619AHBQ06XA3 619AHBQ09XA3 619AHBQ12XA3 619AHBQ18XA3 619AHBQ24XA3 619AHBQ30XA3 619AHBQ36XA3
Electrical
Voltage, Phase,
Cycle
V/Ph/Hz 115-1-60 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
Power Supply Indoor unit powered from outdoor unit
MCA A. 0.2500 0.3125 0.3125 0.3125 0.1625 0.6250 0.6250 0.6250
Controls
Wireless Remote
Controller
(°F/°C Convertible)
Standard Standard Standard Standard Standard Standard Standard Standard
Wired Remote
Controller
(°F/°C Convertible)
Optional Optional Optional Optional Optional Optional Optional Optional
24V Interface for 3rd
Part Thermostat
Control
Optional Optional Optional Optional Optional Optional Optional Optional
Wi-Fi Control for
Phone App Control
Optional Optional Optional Optional Optional Optional Optional Optional
Operating Range
Cooling Indoor DB
Min - Max
°F(°C) 63~90 (17~32) 63~90 (17~32) 63~90 (17~32) 63~90 (17~32) 63~90 (17~32) 63~90 (17~32) 63~90 (17~32) 63~90 (17~32)
Heating Indoor DB
Min - Max
°F(°C) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30)
Piping
Pipe Connection
Size - Liquid
in (mm) 1/4 (6.35) 1/4 (6.35) 1/4 (6.35) 1/4 (6.35) 1/4 (6.35) 3/8 (9.52) 3/8 (9.52) 3/8 (9.52)
Pipe Connection
Size - Suction
in (mm) 1/2 (12.7) 3/8 (9.52) 3/8 (9.52) 1/2 (12.7) 1/2 (12.7) 5/8 (16) 5/8 (16) 5/8 (16)
Indoor Coil
Face Area Sq. Ft. 2.15 2.15 2.15 2.15 2.75 3.60 3.60 3.60
No. Rows 2 2 2 2 2 3 3 3
Fins per inch 20 20 20 20 20 20 20 20
Circuits 3 3 3 3 4 7 7 7
Indoor
Unit Width in (mm) 31.3 (795) 31.3 (795) 31.3 (795) 31.3 (795) 37.99 (965) 44.88 (1140) 44.88 (1140) 44.88 (1140)
Unit Height in (mm) 11.61 (295) 11.61 (295) 11.61 (295) 11.61 (295) 12.56 (319) 14.57 (370) 14.57 (370) 14.57 (370)
Unit Depth in (mm) 8.86 (225) 8.86 (225) 8.86 (225) 8.86 (225) 9.41 (239) 10.83 (275) 10.83 (275) 10.83 (275)
Net Weight lbs (kg) 22.93 (10.4) 22.71 (10.3) 22.71 (10.3) 22.93 (10.4) 27.12 (12.3) 43.65 (19.8) 43.65 (19.8) 43.65 (19.8)
Fan Speeds 4 4 4 4 4 4 4 4
Airflow
(lowest to highest)
CFM 235/294/353/412 176/229/335/382 176/229/335/382 176/229/335/382 306/376/524/635 319/414/611/719 382/505/646/843 382/506/639/843
Sound Pressure
(lowest to highest)
dB(A) 24/30/41/47 32/34/38/47 32/34/38/47 30/32/37/47 37/40/46/48 37/39/44/52 38/41/46/52 39/41/46/52
Air throw Data ft (m) 27.9 (8.5)
24.9 (7.6) 26.2 (8.0) 27.9 (8.5) 31.5 (9.6) 33.8 (10.3) 33.8 (10.3)
Moisture removal
Pint/h
(L/h)
1.16(58) 0.35(18) 1.11(56) 2.18(110) 2.6(132) 3.7(199) 5.75 (291)
Field Drain Pipe
Size O.D.
in (mm) 0.625 (16) 0.625 (16) 0.625 (16) 0.625 (16) 0.625 (16) 0.625 (16) 0.625 (16) 0.625 (16)
Indoor Unit 619AHBQ12XA1 619AHBQ06XA3 619AHBQ09XA3 619AHBQ12XA3 619AHBQ18XA3 619AHBQ24XA3 619AHBQ30XA3 619AHBQ36XA3
Outdoor Unit
Single Zone
38MARBQ12AA1
38MARBQ09AA3 38MARBQ12AA3 38MARBQ18AA3 38MARBQ24AA3 38MARBQ30AA3 38MARBQ36AA3
Outdoor Unit
Multi-zone
38MGRQ18B--3
38MGRQ24C--3
38MGRQ30D--3
38MGRQ36D--3
38MGRQ48E--3
