2 Specifications subject to change without notice. SM619PHA-03
MODEL NUMBER NOMENCLATURE
Table 1 —Unit Sizes
SYSTEMS TONS VOLTAGE/PH/HZ INDOOR MODEL
9
208-230/1/60
619PHAQ09XA3
12 619PHAQ12XA3
18 619PHAQ18XA3
24 619PHAQ24XA3
INDOOR UNIT
619 P H A Q
09 X 3
619 = FAN COIL UNIT
P = MODEL
VOLTAGE
3 = 208/230-1-60
SYSTEM TYPE
H = HIGH WALL
MAJOR SERIES
X = NOT USED
NOMINAL CAPACITY
09 - 3/4 TON
12 - 1 TON
18 - 1.5 TONS
24 - 2 TONS
A
A = VARIATION
INDOOR FAN COIL TYPE
Q = HEAT PUMP
12 19 10001
Week of Manufacture
Sequential Serial Number
V
V = ALL MODELSYear of Manufacture
Use of the AHRI Certified
TM Mark indicates a
manufacturer’s
participation in the
program For verification
of certification for individual
products, go to
www.ahridirectory.org.
