Bryant 619PHA Series User Manual

SM619PHA-03 Specifications subject to change without notice. 3
SPECIFICATIONS
Table 2 — Specifications
*Performance may vary based on the compatible outdoor units. See respective pages for performance data.
SYSTEM
SIZE 9 12 18 24
Indoor Model 619PHAQ09XA3 619PHAQ12XA3 619PHAQ18XA3 619PHAQ24XA3
ELECTRICAL
Voltage, Phase, Cycle V/Ph/Hz 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
Power Supply Indoor unit powered from outdoor unit
MCA A. 0.3 0.3 0.5 0.5
CONTROLS
Wireless Remote controller
(°F/°C Convertible)
Standard Standard Standard Standard
Wired Remote controller
(°F/°C Convertible)
Optional Optional Optional Optional
OPERATING
RANGE
Cooling Indoor DB Min - Max °F (°C) 62~90 (17~32) 62~90 (17~32) 62~90 (17~32) 62~90 (17~32)
Heating Indoor DB Min - Max °F (°C) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30) 32~86 (0~30)
PIPING
Pipe Connection Size - Liquid in (mm) 1/4 (6.35) 1/4 (6.35) 3/8” (9.52) 3/8” (9.52)
Pipe Connection Size - Suction in (mm) 3/8 (9.52) 1/2 (12.7) 5/8” (15.9) 5/8” (15.9)
INDOOR COIL
Face Area (sq. ft.) Sq. Ft. 2.2 2.2 3.9 3.9
No. Rows 4 4 3 3
Fins per inch 21 21 21 21
Circuits 5 5 7 7
INDOOR
Unit Width in (mm) 35.2 (895) 35.2 (895) 49.57 (1259) 49.57 (1259)
Unit Height in (mm) 11.7 (298) 11.7 (298) 14.25 (362) 14.25 (362)
Unit Depth in (mm) 9.8 (248) 9.8 (248) 11.10 (282) 11.10 (282)
Net Weight lbs (kg) 37.48 (17) 37.48 (17) 43.4 (19.7) 43.4 (19.7)
Number of Fan Speeds 4 4 4 4
Airflow (lowest to highest) CFM 144/245/295/345 168/252/306/357 261/389/528/926 359/470/583/926
Sound Pressure (lowest to highest) dB(A) 29/35.5/41.5/45.6 29/35.5/41.5/46.8 35.1/40.8/46.1/55.9 36.1/43.3/46.4/56.5
Air throw Data ft (m) 21.98 (6.7) 22.97 (7) 28.80 (8.7) 31.66 (9.65)
Moisture removal
Pint/h
(L/h)
2.11 (1.0) 2.53 (1.2) 3.8 (1.8) 5.0 (2.39)
Field Drain Pipe Size O.D. in (mm) 1 (25.4) 1 (25.4) 1 (25.4) 1 (25.4)

Bryant 619PHA Series Specifications

General

Brand	Bryant
Model	619PHA Series
Category	Air Handlers
Language	English
