CLEARANCES
Fig. 3 — Indoor Unit Clearances
NOTE: The top clearance recommended for proper return airflow is 5.9 in (15cm). Reduction of this clearance may
decrease the performance of these units. This may be reduced to 3.2 in (80mm) as long as the right and left
clearances are achieved.
4.75 in
(12 cm)
min.
6 ft
(1.8m)
CEILING
FLOOR
5.9in. (15cm) min.
4.75 in
(12 cm)
min.
