Bryant 619PHA Series - Sizes 18 K and 24 K Dimensions

SM619PHA-03 Specifications subject to change without notice. 5
Sizes 18K and 24K
Table 4 — Dimension Sizes 18K and 24K
Fig. 2 — Sizes 18K and 24K
HIGH WALL UNIT SIZE 18K 24K
Voltage (208/230V) (208/230V)
Height In. (mm) 14.25 (362) 14.25 (362)
Width In. (mm) 49.57 (1259) 49.57 (1259)
Depth In. (mm) 11.10 (282) 11.10 (282)
Weight-Net Lbs (kg) 43.4 (19.7) 43.4 (19.7)
Piping
Drain Hose
