Bryant LEGACY 213R User Manual

17
COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
Series
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace ModelFactory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
ECOP
H
Capacity
HCOP
048---A
CNRH*6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.22 29,800 2.48 8.0 355AAV060080
CNRH*6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.24 29,600 2.48 8.1 355AAV060100
CNRH*6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.22 29,600 2.48 8.1 355AAV060120
CNRH*6024A** 45,500 TDR&TXV 13.20 11.00 47,500 3.24 29,600 2.50 8.1 315(A,J)AV048090
CNRH*6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.26 29,600 2.50 8.1 315(A,J)AV060110
CNRH*6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.28 29,400 2.52 8.2 315(A,J)AV066135
CNRH*6024A** 46,000 TDR&TXV 13.50 11.20 47,500 3.30 29,400 2.54 8.2 315(A,J)AV066155
CSRH*4812A* * 44,500 TDR&TXV 13.00 10.80 47,500 3.20 31,200 2.94 8.5 355AAV060080
CSRH*4812A* * 44,500 TDR&TXV 13.00 10.80 47,500 3.22 31,200 2.96 8.6 355AAV060100
CSRH*4812A* * 44,500 TDR&TXV 13.00 10.80 47,500 3.22 31,000 2.96 8.6 355AAV060120
CSRH*4812A* * 45,000 TDR&TXV 13.00 10.80 47,500 3.22 31,000 2.96 8.6 315(A,J)AV048090
CSRH*4812A* * 44,500 TDR&TXV 13.20 11.00 47,500 3.24 31,000 2.98 8.6 315(A,J)AV060110
CSRH*4812A* * 44,500 TDR&TXV 13.20 11.00 47,500 3.26 31,000 3.00 8.7 315(A,J)AV066135
CSRH*4812A* * 45,000 TDR&TXV 13.50 11.20 47,500 3.30 30,800 3.02 8.7 315(A,J)AV066155
CSRH*6012A* * 45,500 TDR&TXV 13.20 11.00 48,000 3.26 29,800 2.48 8.1 355AAV060080
CSRH*6012A* * 46,000 TDR&TXV 13.20 11.00 48,000 3.28 29,600 2.50 8.2 355AAV060100
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.26 29,600 2.50 8.1 355AAV060120
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.28 29,600 2.50 8.2 315(A,J)AV048090
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.30 29,600 2.52 8.2 315(A,J)AV060110
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.32 29,400 2.54 8.3 315(A,J)AV066135
CSRH*6012A* * 46,000 TDR&TXV 13.50 11.20 47,500 3.34 29,400 2.54 8.3 315(A,J)AV066155
060---A
*FC4DN(F,B)060 59,500 TDR&TXV 13.00 10.80 58,500 3.46 37,200 2.50 7.9
FK4DNB006 58,500 TDR&TXV 13.20 11.00 59,500 3.34 38,000 2.40 7.7
CAR**6024A** 57,500 TDR&TXV 13.00 10.80 58,500 3.38 36,600 2.46 7.7 315(A,J)AV066135
CAR**6024A** 58,000 TDR&TXV 13.00 10.80 58,500 3.40 36,400 2.48 7.8 315(A,J)AV066155
CNRV*6024A** 57,500 TDR&TXV 13.00 10.80 59,000 3.36 36,400 2.46 7.7 315(A,J)AV066155
CNRH*6024A** 57,500 TDR&TXV 13.00 10.80 59,000 3.36 36,400 2.46 7.7 315(A,J)AV066155
CSRH*6012A* * 57,500 TDR&TXV 13.00 10.80 59,000 3.42 36,400 2.48 7.8 315(A,J)AV066135
CSRH*6012A* * 58,000 TDR&TXV 13.00 10.80 59,000 3.46 36,400 2.48 7.8 315(A,J)AV066155
* Ratings are net values reflecting the effects of circulating fan heat. Supplemental electric heat is not included. Ratings are based on:
Cooling Standard: 80_F(27_C) db 67_F(19_C) wb indoor entering air temperature and 95_F(35_C) db air entering outdoor unit.
High--- Temp Heating Standard: 70_F(21_C) db indoor entering air temperature and 47_F(8_C) db 43˚F(6_C) wb air entering outdoor unit.
Low---Temp Heating Standard: 70_F(21_C) db indoor entering air temperature and 17_F(±9_C) db 15˚F(±10_C) wb air entering outdoor unit.
SEER — Seasonal Energy Efficiency Ratio
COP — Coefficient of Performance
TDR — Time---Delay Relay
HSPF — Heating Seasonal Performance Factor
EER — Energy Efficiency Ratio
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
