18
DETAILED COOLING CAPACITIES
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM
EW
B
Capacity
MBtuh†
Total
Sys-
tem
KW**
Capacity
MBtuh†
Total
Sys-
tem
KW**
Capacity
MBtuh†
Total
Sys-
tem
KW**
Capacity
MBtuh†
Total
Sys-
tem
KW**
Capacity
MBtuh†
Total
Sys-
tem
KW**
Capacity
MBtuh†
Total
Sys-
tem
KW**
Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
213RNA018--- A Outdoor Section With FA4CNF018 Indoor Section
525
72 20.06 10.33 1.19 19.34 10.06 1.33 18.59 9.77 1.48 17.79 9.46 1.65 16.96 9.15 1.84 16.08 8.83 2.05
67 18.25 12.89 1.19 17.57 12.59 1.33 16.85 12.28 1.48 16.09 11.97 1.65 15.30 11.64 1.83 14.49 11.30 2.04
63 16.94 12.44 1.19 16.28 12.14 1.32 15.59 11.82 1.47 14.88 11.50 1.64 14.13 11.16 1.83 13.35 10.82 2.03
62 16.64 15.38 1.18 16.00 15.05 1.32 15.35 14.70 1.47 14.67 14.33 1.64 13.95 13.95 1.83 13.32 13.32 2.03
57 16.16 16.16 1.18 15.64 15.64 1.32 15.10 15.10 1.47 14.53 14.53 1.64 13.94 13.94 1.83 13.32 13.32 2.03
600
72 20.39 10.80 1.22 19.65 10.52 1.36 18.87 10.23 1.51 18.05 9.92 1.68 17.19 9.61 1.87 16.29 9.28 2.08
67 18.55 13.67 1.22 17.84 13.37 1.36 17.10 13.06 1.51 16.32 12.74 1.68 15.51 12.40 1.86 14.67 12.05 2.07
63 17.22 13.17 1.21 16.55 12.87 1.35 15.84 12.55 1.50 15.09 12.21 1.67 14.32 11.87 1.86 13.53 11.51 2.06
62 16.98 16.37 1.21 16.34 16.01 1.35 15.66 15.66 1.50 15.04 15.04 1.67 14.41 14.41 1.86 13.76 13.76 2.06
57 16.75 16.75 1.21 16.21 16.21 1.35 15.64 15.64 1.50 15.04 15.04 1.67 14.42 14.42 1.86 13.76 13.76 2.06
675
72 20.63 11.24 1.25 19.87 10.95 1.39 19.07 10.66 1.54 18.23 10.35 1.71 17.35 10.04 1.90 16.43 9.70 2.11
67 18.77 14.41 1.25 18.05 14.11 1.38 17.28 13.79 1.54 16.49 13.46 1.71 15.66 13.12 1.89 14.80 12.76 2.10
63 17.44 13.87 1.24 16.74 13.55 1.38 16.01 13.23 1.53 15.25 12.89 1.70 14.47 12.53 1.89 13.65 12.16 2.09
62 17.27 17.27 1.24 16.67 16.67 1.38 16.08 16.08 1.53 15.46 15.46 1.70 14.80 14.80 1.89 14.12 14.12 2.09
57 17.24 17.24 1.24 16.68 16.68 1.38 16.08 16.08 1.53 15.46 15.46 1.70 14.81 14.81 1.89 14.13 14.13 2.09
Cooling Indoor Model Capacity Power Furnace Model
*FA4CN(F,C)018 1.00 1.00
FA4CN(F,C)024 1.01 1.01
FC4DNF018 1.02 0.94
FC4DNF024 1.03 0.93
FF1ENE018 1.00 1.00
FF1ENE024 1.01 1.01
FK4DNF001 1.02 0.92
FK4DNF002 1.04 0.89
CAR**1814A** 0.99 0.99
CAR**2414A** 1.02 1.02
CAR**2417A** 1.02 1.02
CNRF*2418A** 1.02 1.02
CNRH*2417A** 1.02 1.02
CNRV*1814A** 0.99 0.99
CNRV*2414A** 1.02 1.02
CNRV*2417A** 1.02 1.02
CSRH*2412A** 1.02 1.02
CAR**1814A** 0.99 0.91 315(A,J)AV036070
CAR**2414A** 1.01 0.91 315(A,J)AV036070
CNRH*2417A** 1.02 0.92 315(A,J)AV036070
CNRV*1814A** 0.99 0.89 315(A,J)AV036070
CNRV*2414A** 1.01 0.91 315(A,J)AV036070
CSRH*2412A** 1.01 0.91 315(A,J)AV036070
CAR**2417A** 1.02 0.92 315(A,J)AV048090
CNRH*2417A** 1.02 0.92 315(A,J)AV048090
CNRV*2417A** 1.02 0.92 315(A,J)AV048090
CSRH*2412A** 1.02 0.92 315(A,J)AV048090
CNRH*2417A** 1.01 0.91 355AAV042040
CSRH*2412A** 1.01 0.91 355AAV042040
CAR**2417A** 1.01 0.91 355AAV042060
CNRH*2417A** 1.01 0.91 355AAV042060
CNRV*2417A** 1.01 0.91 355AAV042060
CSRH*2412A** 1.01 0.91 355AAV042060
CNRH*2417A** 1.02 0.92 355AAV042080
CSRH*2412A** 1.02 0.92 355AAV042080
See notes on pg. 24
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
