Bryant LEGACY 213R User Manual

10
COMBINATION RATINGS
Unit Size
--- S e r i e s
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace ModelFactory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
ECOP
H
Capacity
HCOP
018---A
*FA4CN(F,C)018 17,100 TDR&TXV 13.00 10.80 18,000 3.52 10,500 2.34 8.0
FA4CN(F,C)024 17,200 TDR&TXV 13.00 10.80 16,000 3.30 10,500 2.34 7.9
FC4DNF018 17,500 TDR&TXV 14.00 11.70 17,500 3.80 10,100 2.52 8.5
FC4DNF024 17,600 TDR&TXV 14.00 12.00 15,400 3.60 10,000 2.56 8.5
FF1ENE018 17,100 TDR&TXV 13.00 10.80 18,000 3.54 10,500 2.36 8.0
FF1ENE024 17,300 TDR&TXV 13.00 10.80 15,600 3.32 10,500 2.38 8.0
FK4DNF001 17,500 TDR&TXV 14.00 12.00 14,600 3.48 9,900 2.54 8.4
FK4DNF002 17,700 TDR&TXV 14.00 12.50 14,600 3.58 9,900 2.58 8.6
CAR**1814A** 16,900 TXV 13.00 10.80 18,100 3.46 10,400 2.34 7.9
CAR**1814A** 16,900 TDR&TXV 14.00 11.70 18,000 3.70 9,800 2.46 8.2 315(A,J)AV036070
CAR**2414A** 17,400 TXV 13.00 10.80 15,700 3.34 10,500 2.40 8.1
CAR**2414A** 17,300 TDR&TXV 14.00 12.00 15,600 3.70 9,900 2.50 8.4 315(A,J)AV036070
CAR**2417A** 17,400 TXV 13.00 10.80 15,700 3.34 10,500 2.40 8.1
CAR**2417A** 17,300 TDR&TXV 14.00 12.00 15,600 3.70 9,900 2.52 8.4 355AAV042060
CAR**2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.70 9,900 2.52 8.6 315(A,J)AV048090
CNRV*1814A** 16,900 TXV 13.00 10.80 17,200 3.52 10,500 2.40 8.1
CNRV*1814A** 16,900 TDR&TXV 14.00 12.00 17,100 3.88 9,900 2.50 8.5 315(A,J)AV036070
CNRV*2414A** 17,400 TXV 13.00 10.80 15,700 3.44 10,500 2.40 8.2
CNRV*2414A** 17,300 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 315(A,J)AV036070
CNRV*2417A** 17,400 TXV 13.00 10.80 15,700 3.44 10,500 2.40 8.2
CNRV*2417A** 17,300 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 355AAV042060
CNRV*2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.54 8.5 315(A,J)AV048090
CNRH*2417A** 17,400 TXV 13.00 10.80 15,700 3.44 10,500 2.40 8.2
CNRH*2417A** 17,300 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 355AAV042040
CNRH*2417A** 17,300 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 355AAV042060
CNRH*2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.82 9,900 2.52 8.5 355AAV042080
CNRH*2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.52 8.5 315(A,J)AV036070
CNRH*2417A** 17,400 TDR&TXV 14.00 12.00 15,600 3.84 9,900 2.54 8.5 315(A,J)AV048090
CNRF*2418A** 17,400 TXV 13.00 10.80 15,700 3.44 10,500 2.40 8.2
CSRH*2412A* * 17,400 TXV 13.00 10.80 14,800 3.26 10,500 2.42 8.0
CSRH*2412A* * 17,300 TDR&TXV 14.00 12.00 14,800 3.62 9,900 2.52 8.5 355AAV042040
CSRH*2412A* * 17,300 TDR&TXV 14.00 12.00 14,800 3.62 9,900 2.52 8.5 355AAV042060
CSRH*2412A* * 17,400 TDR&TXV 14.00 12.00 14,800 3.60 9,900 2.52 8.5 355AAV042080
CSRH*2412A* * 17,300 TDR&TXV 14.00 12.00 14,800 3.62 9,900 2.52 8.5 315(A,J)AV036070
CSRH*2412A* * 17,400 TDR&TXV 14.00 12.00 14,800 3.62 9,900 2.52 8.5 315(A,J)AV048090
024---A
*FA4CN(F,C)024 22,600 TDR&TXV 13.00 10.80 23,800 3.52 14,400 2.36 7.9
FA4CN(F,C)030 22,800 TDR&TXV 13.00 10.80 22,600 3.46 14,400 2.38 7.9
FC4DNF024 23,000 TDR&TXV 14.00 11.50 23,400 3.70 13,900 2.48 8.3
FC4DNF030 23,200 TDR&TXV 14.00 11.50 22,200 3.66 13,900 2.52 8.4
FF1ENE030 22,600 TDR&TXV 13.00 10.80 23,600 3.52 14,400 2.36 8.0
FK4DNF001 23,000 TDR&TXV 14.00 11.70 22,600 3.66 13,700 2.48 8.3
FK4DNF002 23,200 TDR&TXV 14.00 11.70 22,600 3.78 13,700 2.54 8.5
FK4DNF003 23,200 TDR&TXV 14.00 11.70 20,800 3.60 13,600 2.54 8.5
CAR**2414A** 22,800 TXV 13.00 10.80 23,800 3.56 14,400 2.38 8.1
CAR**2414A** 22,800 TDR&TXV 14.00 11.50 23,800 3.72 13,700 2.46 8.3 315(A,J)AV036070
CAR**2417A** 22,800 TXV 13.00 10.80 23,800 3.56 14,400 2.38 8.1
CAR**2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.74 13,700 2.48 8.3 355AAV042060
CAR**2417A** 22,800 TDR&TXV 14.00 11.70 23,600 3.76 13,600 2.50 8.4 315(A,J)AV048090
CAR**3014A** 22,800 TXV 13.00 10.80 20,800 3.30 14,500 2.38 7.8
CAR**3014A** 22,800 TDR&TXV 14.00 11.50 22,000 3.58 13,700 2.48 8.2 315(A,J)AV036070
CAR**3017A** 22,800 TXV 13.00 10.80 20,800 3.30 14,500 2.38 7.8
CAR**3017A** 22,800 TDR&TXV 14.00 11.70 20,800 3.60 13,700 2.50 8.3 355AAV042060
CAR**3017A** 23,000 TDR&TXV 14.00 11.70 20,800 3.62 13,600 2.52 8.3 315(A,J)AV048090
See notes on pg. 17
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
