COMBINATION RATINGS -- CONTINUED
Unit Size
--- S e r i e s
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace ModelFactory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
ECOP
H
Capacity
HCOP
024---A
CNRV*2414A** 22,800 TXV 13.00 10.80 23,800 3.66 14,500 2.38 8.2
CNRV*2414A** 22,600 TDR&TXV 14.00 11.50 23,800 3.80 13,700 2.48 8.4 315(A,J)AV036070
CNRV*2417A** 22,800 TXV 13.00 10.80 23,800 3.66 14,500 2.38 8.2
CNRV*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.82 13,700 2.48 8.4 355AAV042060
CNRV*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.84 13,700 2.50 8.5 315(A,J)AV048090
024---A
CNRV*3014A** 22,800 TXV 13.00 10.80 20,600 3.28 14,500 2.40 7.8
CNRV*3014A** 22,800 TDR&TXV 14.00 11.50 20,600 3.58 13,700 2.48 8.2 315(A,J)AV036070
CNRV*3017A** 22,800 TXV 13.00 10.80 20,600 3.28 14,500 2.40 7.8
CNRV*3017A** 22,800 TDR&TXV 14.00 11.70 20,600 3.60 13,700 2.50 8.3 355AAV042060
CNRV*3017A** 23,000 TDR&TXV 14.00 11.70 20,600 3.62 13,600 2.52 8.4 315(A,J)AV048090
CNRH*2417A** 22,800 TXV 13.00 10.80 23,800 3.66 14,500 2.38 8.2
CNRH*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.82 13,800 2.48 8.4 355AAV042040
CNRH*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.82 13,700 2.48 8.4 355AAV042060
CNRH*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.82 13,800 2.48 8.4 355AAV042080
CNRH*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.82 13,800 2.48 8.4 355AAV060080
CNRH*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.84 13,800 2.50 8.4 355AAV060100
CNRH*2417A** 22,600 TDR&TXV 14.00 11.50 23,600 3.80 13,700 2.48 8.4 355AAV060120
CNRH*2417A** 22,600 TDR&TXV 14.00 11.50 23,600 3.80 13,700 2.48 8.4 315(A,J)AV036070
CNRH*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.84 13,700 2.50 8.5 315(A,J)AV048090
CNRH*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.82 13,800 2.48 8.4 315(A,J)AV060110
CNRH*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.84 13,800 2.50 8.5 315(A,J)AV066135
CNRH*2417A** 22,800 TDR&TXV 14.00 11.50 23,600 3.84 13,700 2.50 8.5 315(A,J)AV066155
CNRH*3017A** 22,800 TXV 13.00 10.80 20,600 3.28 14,500 2.40 7.8
CNRH*3017A** 22,800 TDR&TXV 14.00 11.70 20,600 3.60 13,700 2.50 8.3 355AAV042040
CNRH*3017A** 22,800 TDR&TXV 14.00 11.70 20,600 3.60 13,700 2.50 8.3 355AAV042060
CNRH*3017A** 22,800 TDR&TXV 14.00 11.70 20,600 3.60 13,700 2.50 8.3 355AAV042080
CNRH*3017A** 22,800 TDR&TXV 14.00 11.70 20,600 3.60 13,700 2.50 8.3 355AAV060080
CNRH*3017A** 22,800 TDR&TXV 14.00 11.70 20,600 3.60 13,700 2.52 8.4 355AAV060100
CNRH*3017A** 22,800 TDR&TXV 14.00 11.70 20,600 3.60 13,700 2.50 8.2 355AAV060120
CNRH*3017A** 22,800 TDR&TXV 14.00 11.70 20,600 3.60 13,700 2.50 8.2 315(A,J)AV036070
CNRH*3017A** 23,000 TDR&TXV 14.00 11.70 20,600 3.62 13,600 2.52 8.4 315(A,J)AV048090
CNRH*3017A** 23,000 TDR&TXV 14.00 11.70 20,600 3.62 13,700 2.50 8.4 315(A,J)AV060110
CNRH*3017A** 23,000 TDR&TXV 14.00 11.70 20,600 3.62 13,700 2.52 8.4 315(A,J)AV066135
CNRH*3017A** 23,000 TDR&TXV 14.00 11.70 20,600 3.62 13,700 2.52 8.4 315(A,J)AV066155
CNRF*2418A** 22,800 TXV 13.00 10.80 23,800 3.66 14,500 2.38 8.2
CSRH*2412A* * 22,800 TXV 13.00 10.80 23,000 3.56 14,500 2.40 8.2
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.50 23,000 3.74 13,800 2.48 8.4 355AAV042040
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.50 23,000 3.74 13,800 2.48 8.4 355AAV042060
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.50 23,000 3.74 13,800 2.48 8.4 355AAV042080
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.50 23,000 3.74 13,800 2.48 8.4 355AAV060080
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.50 23,000 3.76 13,800 2.50 8.4 355AAV060100
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.50 23,000 3.74 13,800 2.48 8.3 355AAV060120
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.50 23,000 3.74 13,800 2.48 8.4 315(A,J)AV036070
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.70 23,000 3.76 13,700 2.50 8.4 315(A,J)AV048090
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.50 23,000 3.74 13,800 2.48 8.4 315(A,J)AV060110
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.50 23,000 3.76 13,800 2.50 8.4 315(A,J)AV066135
CSRH*2412A* * 22,800 TDR&TXV 14.00 11.70 23,000 3.76 13,800 2.50 8.4 315(A,J)AV066155
CSRH*3012A* * 22,800 TXV 13.00 10.80 20,200 3.26 14,500 2.40 7.8
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.56 13,700 2.50 8.3 355AAV042040
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.58 13,700 2.50 8.3 355AAV042060
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.56 13,700 2.50 8.3 355AAV042080
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.58 13,700 2.50 8.3 355AAV060080
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.58 13,700 2.50 8.3 355AAV060100
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.58 13,700 2.48 8.3 355AAV060120
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.58 13,700 2.48 8.3 315(A,J)AV036070
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.60 13,700 2.50 8.3 315(A,J)AV048090
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.58 13,700 2.50 8.3 315(A,J)AV060110
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.58 13,700 2.50 8.3 315(A,J)AV066135
CSRH*3012A* * 22,800 TDR&TXV 14.00 11.70 20,200 3.58 13,700 2.50 8.3 315(A,J)AV066155
See notes on pg. 17
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
