COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
Series
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace ModelFactory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
ECOP
H
Capacity
HCOP
030---A
*FA4CN(F,C)030 28,400 TDR&TXV 13.00 10.80 30,200 3.46 18,700 2.42 8.1
FC4DNF030 28,800 TDR&TXV 13.50 11.20 29,800 3.60 18,300 2.52 8.3
FC4DN(F,B)036 29,200 TDR&TXV 14.00 11.50 29,000 3.58 18,400 2.54 8.4
FF1ENE030 28,200 TDR&TXV 13.00 10.50 30,000 3.44 18,700 2.42 8.0
FF1ENE036 28,800 TDR&TXV 13.00 10.80 29,400 3.44 18,800 2.44 8.1
FK4DNF001 28,400 TDR&TXV 13.50 11.20 29,600 3.50 18,100 2.48 8.1
FK4DNF002 28,600 TDR&TXV 14.00 11.50 29,800 3.66 18,100 2.54 8.4
FK4DNF003 28,800 TDR&TXV 14.00 11.70 29,000 3.60 17,900 2.56 8.4
FK4DNF005 29,800 TDR&TXV 14.00 12.00 25,000 3.46 18,000 2.64 8.5
CAR**3014A** 28,600 TXV 13.00 10.50 29,600 3.44 18,900 2.44 8.1
CAR**3014A** 28,400 TDR&TXV 13.50 11.20 29,200 3.52 18,100 2.50 8.2 315(A,J)AV036070
CAR**3017A** 28,600 TXV 13.00 10.50 29,600 3.44 18,900 2.44 8.1
CAR**3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.52 18,000 2.50 8.2 355AAV042060
CAR**3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.54 17,900 2.52 8.2 315(A,J)AV048090
CAR**3614A** 28,400 TXV 13.00 10.50 29,400 3.44 18,900 2.44 8.1
CAR**3614A** 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,100 2.50 8.2 315(A,J)AV036070
CAR**3617A** 28,600 TXV 13.00 10.50 29,400 3.44 18,900 2.44 8.1
CAR**3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.54 18,000 2.52 8.3 355AAV042060
CAR**3617A** 28,600 TDR&TXV 14.00 11.50 29,000 3.58 17,900 2.52 8.3 315(A,J)AV048090
CAR**3621A** 28,600 TXV 13.00 10.50 29,400 3.44 18,900 2.44 8.1
CAR**3621A** 28,600 TDR&TXV 14.00 11.50 29,000 3.58 18,000 2.52 8.3 355AAV042080
CAR**3621A** 28,600 TDR&TXV 14.00 11.50 29,000 3.56 18,000 2.52 8.3 355AAV060080
CAR**3621A** 28,600 TDR&TXV 14.00 11.50 29,000 3.58 18,000 2.52 8.3 355AAV060100
CAR**3621A** 28,600 TDR&TXV 14.00 11.50 29,000 3.60 18,000 2.54 8.3 315(A,J)AV060110
CNRV*3014A** 28,600 TXV 13.00 10.50 29,600 3.44 18,900 2.44 8.1
CNRV*3014A** 28,400 TDR&TXV 13.50 11.20 29,200 3.52 18,100 2.48 8.2 315(A,J)AV036070
CNRV*3017A** 28,600 TXV 13.00 10.50 29,600 3.44 18,900 2.44 8.1
CNRV*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.52 18,000 2.50 8.2 355AAV042060
CNRV*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.56 18,000 2.52 8.3 315(A,J)AV048090
CNRV*3617A** 28,600 TXV 13.00 10.50 29,400 3.46 18,900 2.44 8.1
CNRV*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.52 18,000 2.50 8.2 355AAV042060
CNRV*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.56 18,000 2.52 8.3 315(A,J)AV048090
CNRV*3621A** 28,600 TXV 13.00 10.50 29,400 3.46 18,900 2.44 8.1
CNRV*3621A** 28,400 TDR&TXV 14.00 11.50 29,000 3.54 18,100 2.50 8.2 355AAV042080
CNRV*3621A** 28,400 TDR&TXV 14.00 11.50 29,000 3.54 18,000 2.50 8.2 355AAV060080
CNRV*3621A** 28,400 TDR&TXV 14.00 11.50 29,000 3.54 18,000 2.52 8.3 355AAV060100
CNRV*3621A** 28,600 TDR&TXV 14.00 11.50 29,000 3.56 18,000 2.52 8.3 315(A,J)AV060110
CNRH*3017A** 28,600 TXV 13.00 10.50 29,600 3.44 18,900 2.44 8.1
CNRH*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.52 18,100 2.50 8.2 355AAV042040
CNRH*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,000 2.50 8.2 355AAV042060
CNRH*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,100 2.50 8.2 355AAV042080
CNRH*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,000 2.50 8.2 355AAV060080
CNRH*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,000 2.52 8.3 355AAV060100
CNRH*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,000 2.50 8.2 355AAV060120
CNRH*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.52 18,100 2.50 8.2 315(A,J)AV036070
CNRH*3017A** 28,400 TDR&TXV 14.00 11.50 29,200 3.56 18,000 2.52 8.3 315(A,J)AV048090
CNRH*3017A** 28,600 TDR&TXV 14.00 11.50 29,200 3.56 18,000 2.52 8.3 315(A,J)AV060110
CNRH*3017A** 28,600 TDR&TXV 14.00 11.50 29,200 3.56 18,000 2.52 8.3 315(A,J)AV066135
CNRH*3017A** 28,600 TDR&TXV 14.00 11.50 29,200 3.58 18,000 2.54 8.3 315(A,J)AV066155
CNRH*3617A** 28,600 TXV 13.00 10.50 29,400 3.44 18,900 2.44 8.1
CNRH*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.52 18,100 2.50 8.2 355AAV042040
CNRH*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.54 18,000 2.50 8.2 355AAV042060
CNRH*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.54 18,100 2.50 8.2 355AAV042080
CNRH*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.54 18,000 2.50 8.2 355AAV060080
CNRH*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.54 18,000 2.52 8.3 355AAV060100
See notes on pg. 17
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
