4
ACCESSORY THERMOSTATS
THERMOSTAT / SUBBASE PKG. DESCRIPTION
TSTATBBPRH01---B*
Thermidistatt Control — Non---Programmable/Programmable Thermostat with
Humidity Control (For use in Dual Fuel, AC, HP, and 2S applications. Includes Out-
door Air Temperature Sensor.)
TSTATBBPHH01---B*
HybridHeatt (Dual Fuel) Thermostat — Auto Changeover, 7---Day Programmable,
°F/°C, Includes Outdoor Sensor (TSTA TXXSEN01--- B)
TSTATBBPHP01---B
Thermostat — Auto Changeover, 7--- Day Programmable, °F/°C , 2 --- S t a g e H e a t ,
1 --- S t a g e C o o l
TSTATBBNHP01---C
Thermostat — Auto Changeover, Non--- Programmable, °F/°C , 2 --- S t a g e H e a t ,
1 --- S t a g e C o o l
TSTATBBSHP01
Standard Programmable Thermostat—Manual Changeover, 5---2 Day Program-
mable, °F/°C , 1 --- S t a g e H e a t / 1 --- S t a g e C o o l
TSTATBBBHP01*--- B
Builder’s Thermostat — Heat Pump, Non--- Programmable, °F/°C , 2 --- S t a g e H e a t ,
1--- Stage Cool, Manual Changeover
TSTATXXSEN01--- B** Outdoor Air Temperature Sensor
TSTATXXNBP01 Backplate for Non--- Programmable Thermostat
TSTATXXPBP01 Backplate for Programmable Thermostat and Thermidistatt Control
TSTATXXSBP01 Backplate for Standard Programmable Thermostat
TSTATXXBBP01 Backplate for Builder’s Thermostat
TSTATXXCNV10{ Thermostat Conversion Kit (4 to 5 Wire) — 10 Pack
* Do not use in zoning heat pump applications.
** Outdoor temperature sensor is an accessory for all Bryant electronic thermostats, except the non ---programmable air conditioner version and builder;s
thermostats. It allows the temperature at a remote location (outdoors) to be displayed on the thermostat. The outdoor air temperature sensor must be used
with the HybridHeatt (dual fuel) thermostat.
{ Th ermostat conversion kit is a 24---vac accessory that can turn a 4---wire thermostat application into a 5---wire application. This kit can also be u sed to
replace a broken thermostat wire, or add an extra wire when needed.
The outdoor air temperature sensor is included with the Thermidistat Control and HybridHeatt (dual fuel) thermostat.
ACCESSORIES
ORDER NUMBER DESCRIPTION (N)
018-- A
(N)
024-- A
(N)
030-- A
(P)
030-- A
(N)
036-- A
(P)
036-- A
(E)
036-- A
(N)
042-- A
(P)
042-- A
(E)
042-- A
(N)
048-- A
(P)
048-- A
(E)
048-- A
(N)
060-- A
(P)
060-- A
(E)
060-- A
HC32GE229 BALL BEARING MOTOR X
HC34GE240 BALL BEARING MOTOR X X X
HC36GE232 BALL BEARING MOTOR X X X X
HC40GE228 BALL BEARING MOTOR X X X X
KAACH1201AAA CRANKCASE HTR X X X X X X S S S S
KAACH1301AAA CRANKCASE HTR X X S S
KAACH1401AAA CRANKCASE HTR X X
KSACY0101AAA CYCLE PROTECTOR X X X X X X X X X X X X X X X X
KAAFT0101AAA FREEZE THERMOSTAT X X X X X X X X X X X X X X X X
KSAHS1501AAA HARD START X X X X X X
KSAHS1601AAA HARD START X
KSAHI0301R22 HIGH PRESS SW X X X X X X X X X X X X X X X X
KHAIR0101AAA ISOLATION RELA Y X X X X X X X X X X X X X X X X
KSALA0201R22 LOW AMBIENT X X X X X X X X X X X X X X X X
KSALA0601AAA MOTORMASTER 230V X X X X X X X X X X X X
KSALA0701AAA MOTORMASTER 460V X X X X
KHAOT0201SEC OUTDOOR THERMO-
ST AT
X X X X X X X X X X X X X X X X
KHAOT0301FST OUTDOOR THERMO-
ST AT
X X X X X X X X X X X X X X X X
KHALS0401LLS SOLENOID VALVE X X X X X X X X X X X X X X X X
KSASH0601COP SOUND BLKT X X X X X X X X X X X
KSASH1801COP SOUND BLKT X X
KSASH2101COP SOUND BLKT X X X
KAACS0201PTC START ASSIST PTC X X X X X X X
KSASF0101AAA SUPPORT FEET X X X X X X X X X X X X X X X X
KAATD0101TDR TIME DELAY X X X X X X X X X X X X X X X X
KSATX0601HSO TXV X X X X X X X X X X
KSATX0701HSO TXV X X X
KSATX1001HSO TXV X X X
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
