13
COMBINATION RATINGS -- CONTINUED
U n i t S i z e ---
Series
Indoor Model
Cooling
Capacity
ARI Standard Ratings
Cooling Heating
Furnace ModelFactory
Enhance
Standard
Rating
SEER
TDR
EER
High Temp Low Temp
HSPF
E
Capacity
ECOP
H
Capacity
HCOP
030---A
CNRH*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.54 18,000 2.50 8.2 355AAV060120
CNRH*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.52 18,100 2.50 8.2 315(A,J)AV036070
CNRH*3617A** 28,400 TDR&TXV 14.00 11.50 29,000 3.56 18,000 2.52 8.3 315(A,J)AV048090
CNRH*3617A** 28,600 TDR&TXV 14.00 11.50 29,000 3.56 18,000 2.52 8.3 315(A,J)AV060110
CNRH*3617A** 28,600 TDR&TXV 14.00 11.50 29,000 3.56 18,000 2.52 8.3 315(A,J)AV066135
CNRH*3617A** 28,600 TDR&TXV 14.00 11.50 29,000 3.58 18,000 2.54 8.3 315(A,J)AV066155
CNRF*3618A** 28,600 TXV 13.00 10.50 29,600 3.46 18,900 2.44 8.1
CSRH*3012A* * 28,800 TXV 13.00 10.50 29,600 3.46 18,900 2.44 8.1
CSRH*3012A* * 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,100 2.50 8.2 355AAV042040
CSRH*3012A* * 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,100 2.50 8.2 355AAV042060
CSRH*3012A* * 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,100 2.50 8.2 355AAV042080
CSRH*3012A* * 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,100 2.50 8.3 355AAV060080
CSRH*3012A* * 28,400 TDR&TXV 14.00 11.50 29,200 3.56 18,100 2.52 8.3 355AAV060100
CSRH*3012A* * 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,000 2.50 8.2 355AAV060120
CSRH*3012A* * 28,400 TDR&TXV 14.00 11.50 29,200 3.54 18,100 2.50 8.2 315(A,J)AV036070
CSRH*3012A* * 28,400 TDR&TXV 14.00 11.50 29,200 3.56 18,000 2.52 8.3 315(A,J)AV048090
CSRH*3012A* * 28,400 TDR&TXV 14.00 11.50 29,200 3.56 18,100 2.52 8.3 315(A,J)AV060110
CSRH*3012A* * 28,600 TDR&TXV 14.00 11.50 29,200 3.58 18,000 2.52 8.3 315(A,J)AV066135
CSRH*3012A* * 28,600 TDR&TXV 14.00 11.50 29,200 3.58 18,000 2.52 8.3 315(A,J)AV066155
CSRH*3612A* * 28,400 TXV 13.00 10.80 29,000 3.50 19,000 2.48 8.3
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.50 28,800 3.62 18,100 2.54 8.4 355AAV042040
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.70 28,800 3.62 18,100 2.54 8.4 355AAV042060
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.70 28,800 3.62 18,100 2.56 8.4 355AAV042080
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.70 28,800 3.62 18,100 2.56 8.4 355AAV060080
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.70 28,800 3.64 18,100 2.56 8.5 355AAV060100
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.70 28,800 3.64 18,000 2.56 8.4 355AAV060120
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.50 28,800 3.62 18,100 2.54 8.4 315(A,J)AV036070
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.70 28,800 3.64 18,000 2.56 8.5 315(A,J)AV048090
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.70 28,600 3.66 18,100 2.56 8.5 315(A,J)AV060110
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.70 28,600 3.66 18,000 2.58 8.5 315(A,J)AV066135
CSRH*3612A* * 28,600 TDR&TXV 14.00 11.70 28,600 3.66 18,000 2.58 8.5 315(A,J)AV066155
036---A
*FC4DN(F,B)036 34,200 TDR&TXV 13.00 --- 11.00 35,200 3.50 21,000 2.46 8.3
FC4DN(F,B)042 35,000 TDR&TXV 13.50 --- 11.20 34,200 3.56 21,200 2.52 8.4
FK4DNF002 33,400 TDR&TXV 13.00 --- 10.80 36,400 3.50 20,800 2.44 8.0
FK4DNF003 33,800 TDR&TXV 13.50 --- 11.20 35,400 3.50 20,600 2.48 8.1
FK4DNF005 35,200 TDR&TXV 14.00 --- 11.50 30,600 3.40 20,600 2.56 8.3
CAR**3614A** 32,400 TDR&TXV 13.00 --- 10.80 34,400 3.40 20,800 2.40 8.0 315(A,J)AV036070
CAR**3617A** 33,400 TDR&TXV 13.20 --- 11.00 35,400 3.42 20,600 2.44 8.0 355AAV042060
CAR**3617A** 33,400 TDR&TXV 13.20 --- 11.00 35,200 3.44 20,600 2.44 8.1 315(A,J)AV048090
CAR**3621A** 33,200 TDR&TXV 13.00 --- 10.80 35,400 3.40 20,800 2.42 8.0 355AAV042080
CAR**3621A** 33,400 TDR&TXV 13.20 --- 10.80 35,400 3.44 20,600 2.44 8.0 355AAV060080
CAR**3621A** 33,400 TDR&TXV 13.20 --- 11.00 35,200 3.44 20,600 2.44 8.1 355AAV060100
CAR**3621A** 33,600 TDR&TXV 13.20 --- 11.00 35,200 3.48 20,600 2.46 8.1 315(A,J)AV060110
CAR**4221A** 33,600 TDR&TXV 13.00 --- 10.80 35,200 3.44 20,800 2.44 8.1 355AAV042080
CAR**4221A** 33,800 TDR&TXV 13.20 --- 11.00 35,200 3.48 20,800 2.46 8.1 355AAV060080
CAR**4221A** 33,800 TDR&TXV 13.20 --- 11.00 35,000 3.50 20,800 2.46 8.1 355AAV060100
CAR**4221A** 33,800 TDR&TXV 13.50 --- 11.20 35,000 3.52 20,600 2.48 8.2 315(A,J)AV060110
CAR**4224A** 33,600 TDR&TXV 13.20 --- 11.00 35,200 3.46 20,800 2.44 8.1 355AAV042040
CAR**4224A** 33,800 TDR&TXV 13.50 --- 11.20 35,000 3.50 20,600 2.46 8.2 355AAV060120
CAR**4224A** 33,800 TDR&TXV 13.50 --- 11.20 35,000 3.52 20,600 2.48 8.2 315(A,J)AV066135
CAR**4224A** 34,000 TDR&TXV 13.50 --- 11.20 34,800 3.56 20,600 2.50 8.3 315(A,J)AV066155
CNRV*3617A** 33,200 TDR&TXV 13.00 --- 10.80 35,400 3.40 20,800 2.42 8.0 355AAV042060
CNRV*3617A** 33,400 TDR&TXV 13.20 --- 11.00 35,200 3.42 20,600 2.44 8.0 315(A,J)AV 048090
CNRV*3621A** 33,200 TDR&TXV 13.00 --- 10.70 35,400 3.36 20,800 2.40 7.9 355AAV042080
CNRV*3621A** 33,200 TDR&TXV 13.00 --- 10.80 35,400 3.40 20,800 2.42 8.0 355AAV060080
CNRV*3621A** 33,400 TDR&TXV 13.00 --- 10.80 35,400 3.40 20,800 2.42 8.0 355AAV060100
CNRV*3621A** 33,400 TDR&TXV 13.20 --- 11.00 35,400 3.44 20,800 2.44 8.0 315(A,J)AV 060110
See notes on pg. 17
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
