DETAILED COOLING CAPACITIES -- CONTINUED
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES deg F
75 85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Capacity
MBtuh†
Total
System
KW**
Total
Sens
‡
Total
Sens
‡
Total
Sens
‡
Total
Sens
‡
Total
Sens
‡
Total
Sens
‡
213RNA024--- A Outdoor Section With FA4CNC024 Indoor Section
700
72 26.55 13.79 1.69 25.58 13.41 1.88 24.57 13.03 2.08 23.52 12.63 2.31 22.41 12.22 2.57 21.24 11.79 2.84
67 24.11 17.20 1.67 23.20 16.81 1.86 22.26 16.42 2.07 21.27 16.00 2.30 20.24 15.57 2.55 19.15 15.12 2.82
63 22.37 16.59 1.66 21.51 16.20 1.85 20.61 15.80 2.06 19.67 15.37 2.28 18.69 14.93 2.53 17.65 14.47 2.80
62 22.00 20.58 1.66 21.18 20.15 1.85 20.32 19.70 2.05 19.44 19.21 2.28 18.57 18.57 2.53 17.73 17.73 2.80
57 21.50 21.50 1.66 20.82 20.82 1.85 20.11 20.11 2.05 19.36 19.36 2.28 18.57 18.57 2.53 17.73 17.73 2.80
800
72 27.00 14.44 1.73 25.99 14.06 1.91 24.95 13.67 2.12 23.86 13.27 2.35 22.71 12.85 2.61 21.51 12.42 2.88
67 24.52 18.28 1.71 23.58 17.89 1.90 22.60 17.49 2.11 21.58 17.07 2.34 20.51 16.62 2.59 19.40 16.16 2.86
63 22.75 17.61 1.70 21.86 17.21 1.89 20.93 16.80 2.10 19.97 16.36 2.32 18.95 15.91 2.57 17.89 15.44 2.84
62 22.48 21.96 1.70 21.64 21.50 1.89 20.83 20.83 2.09 20.04 20.04 2.32 19.21 19.21 2.57 18.34 18.34 2.84
57 22.30 22.30 1.70 21.59 21.59 1.89 20.83 20.83 2.09 20.05 20.05 2.32 19.21 19.21 2.57 18.34 18.34 2.84
900
72 27.33 15.05 1.77 26.29 14.68 1.95 25.22 14.29 2.16 24.10 13.88 2.39 22.93 13.46 2.65 21.69 13.02 2.92
67 24.82 19.32 1.75 23.85 18.92 1.94 22.85 18.51 2.15 21.81 18.07 2.37 20.72 17.62 2.62 19.58 17.15 2.90
63 23.03 18.57 1.74 22.12 18.16 1.93 21.17 17.74 2.13 20.18 17.30 2.36 19.15 16.84 2.61 18.07 16.35 2.88
62 22.97 22.97 1.74 22.22 22.22 1.93 21.43 21.43 2.14 20.61 20.61 2.37 19.74 19.74 2.62 18.83 18.83 2.89
57 22.97 22.97 1.74 22.22 22.22 1.93 21.44 21.44 2.14 20.61 20.61 2.37 19.75 19.75 2.62 18.83 18.83 2.89
Cooling Indoor Model Capacity Power Furnace Model
*FA4CN(F,C)024 1.00 1.00
FA4CN(F,C)030 1.01 1.01
FC4DNF024 1.02 0.96
FC4DNF030 1.03 0.96
FF1ENE030 1.00 1.00
FK4DNF001 1.02 0.94
FK4DNF002 1.03 0.95
FK4DNF003 1.03 0.95
CAR**2414A** 1.01 1.01
CAR**2417A** 1.01 1.01
CAR**3014A** 1.01 1.01
CAR**3017A** 1.01 1.01
CNRF*2418A** 1.01 1.01
CNRH*2417A** 1.01 1.01
CNRH*3017A** 1.01 1.01
CNRV*2414A** 1.01 1.01
CNRV*2417A** 1.01 1.01
CNRV*3014A** 1.01 1.01
CNRV*3017A** 1.01 1.01
CSRH*2412A** 1.01 1.01
CSRH*3012A** 1.01 1.01
CAR**2414A** 1.01 0.95 315(A,J)AV036070
CAR**3014A** 1.01 0.95 315(A,J)AV036070
CNRH*2417A** 1.00 0.94 315(A,J)AV036070
CNRH*3017A** 1.01 0.93 315(A,J)AV036070
CNRV*2414A** 1.00 0.94 315(A,J)AV036070
CNRV*3014A** 1.01 0.95 315(A,J)AV036070
CSRH*2412A** 1.01 0.95 315(A,J)AV036070
CSRH*3012A** 1.01 0.93 315(A,J)AV036070
CAR**2417A** 1.01 0.93 315(A,J)AV048090
CAR**3017A** 1.02 0.94 315(A,J)AV048090
CNRH*2417A** 1.01 0.95 315(A,J)AV048090
CNRH*3017A** 1.02 0.94 315(A,J)AV048090
CNRV*2417A** 1.01 0.95 315(A,J)AV048090
CNRV*3017A** 1.02 0.94 315(A,J)AV048090
CSRH*2412A** 1.01 0.93 315(A,J)AV048090
CSRH*3012A** 1.01 0.93 315(A,J)AV048090
Cooling Indoor Model Capacity Power Furnace Model
CNRH*2417A** 1.01 0.95 315(A,J)AV060110
CNRH*3017A** 1.02 0.94 315(A,J)AV060110
CSRH*2412A** 1.01 0.95 315(A,J)AV060110
CSRH*3012A** 1.01 0.93 315(A,J)AV060110
CNRH*2417A** 1.01 0.95 315(A,J)AV066135
CNRH*3017A** 1.02 0.94 315(A,J)AV066135
CSRH*2412A** 1.01 0.95 315(A,J)AV066135
CSRH*3012A** 1.01 0.93 315(A,J)AV066135
CNRH*2417A** 1.01 0.95 315(A,J)AV066155
CNRH*3017A** 1.02 0.94 315(A,J)AV066155
CSRH*2412A** 1.01 0.93 315(A,J)AV066155
CSRH*3012A** 1.01 0.93 315(A,J)AV066155
CNRH*2417A** 1.01 0.95 355AAV042040
CNRH*3017A** 1.01 0.93 355AAV042040
CSRH*2412A** 1.01 0.95 355AAV042040
CSRH*3012A** 1.01 0.93 355AAV042040
CAR**2417A** 1.01 0.95 355AAV042060
CAR**3017A** 1.01 0.93 355AAV042060
CNRH*2417A** 1.01 0.95 355AAV042060
CNRH*3017A** 1.01 0.93 355AAV042060
CNRV*2417A** 1.01 0.95 355AAV042060
CNRV*3017A** 1.01 0.93 355AAV042060
CSRH*2412A** 1.01 0.95 355AAV042060
CSRH*3012A** 1.01 0.93 355AAV042060
CNRH*2417A** 1.01 0.95 355AAV042080
CNRH*3017A** 1.01 0.93 355AAV042080
CSRH*2412A** 1.01 0.95 355AAV042080
CSRH*3012A** 1.01 0.93 355AAV042080
CNRH*2417A** 1.01 0.95 355AAV060080
CNRH*3017A** 1.01 0.93 355AAV060080
CSRH*2412A** 1.01 0.95 355AAV060080
CSRH*3012A** 1.01 0.93 355AAV060080
CNRH*2417A** 1.01 0.95 355AAV060100
CNRH*3017A** 1.01 0.93 355AAV060100
CSRH*2412A** 1.01 0.95 355AAV060100
CSRH*3012A** 1.01 0.93 355AAV060100
CNRH*2417A** 1.00 0.94 355AAV060120
CNRH*3017A** 1.01 0.93 355AAV060120
CSRH*2412A** 1.01 0.95 355AAV060120
CSRH*3012A** 1.01 0.93 355AAV060120
See notes on pg. 24
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
