HEAT PUMP HEATING PERFORMANCE -- CONTINUED
INDOOR AIR
OUTDOOR COIL ENTERING AIR TEMPERATURES deg F
--- 3 7 17 27 37 47 57 67
EDB CFM
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Capacity
MBtuh
Tot a l
Sys-
tem
KW†
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
Tot a l
In-
teg*
213RNA036--- A Outdoor Section With FC4DNF036 Indoor Section
65
1050 14.65 13.48 2.24 18.17 16.70 2.34 22.00 20.06 2.45 26.27 23.33 2.59 31.04 28.25 2.77 35.48 35.48 2.89 39.50 39.50 3.04 43.82 43.82 3.21
1200 14.85 13.66 2.25 18.38 16.89 2.34 22.25 20.29 2.44 26.56 23.59 2.57 31.27 28.45 2.73 35.09 35.09 2.82 38.97 38.97 2.96 41.96 41.96 3.06
1350 15.02 13.82 2.27 18.57 17.06 2.35 22.47 20.48 2.44 26.83 23.83 2.57 31.26 28.45 2.69 34.70 34.70 2.78 38.35 38.35 2.90 39.33 39.33 2.93
70
1050 14.28 13.13 2.33 17.84 16.39 2.45 21.66 19.75 2.56 25.90 23.00 2.71 30.63 27.87 2.89 35.40 35.40 3.04 39.43 39.43 3.19 43.93 43.93 3.38
1200 14.48 13.32 2.34 18.05 16.59 2.45 21.90 19.97 2.55 26.18 23.25 2.69 30.95 28.16 2.86 35.20 35.20 2.97 39.03 39.03 3.10 43.12 43.12 3.26
1350 14.66 13.48 2.36 18.24 16.76 2.46 22.12 20.17 2.55 26.43 23.47 2.68 31.08 28.29 2.83 34.83 34.83 2.92 38.53 38.53 3.05 40.75 40.75 3.12
75
1050 13.88 12.77 2.43 17.49 16.07 2.55 21.33 19.45 2.68 25.51 22.66 2.83 30.21 27.49 3.02 35.16 35.16 3.20 39.39 39.39 3.35 43.91 43.91 3.55
1200 14.08 12.96 2.44 17.71 16.27 2.55 21.57 19.67 2.67 25.80 22.91 2.81 30.55 27.80 2.98 35.20 35.20 3.12 39.02 39.02 3.26 43.25 43.25 3.43
1350 14.27 13.13 2.46 17.90 16.45 2.56 21.78 19.86 2.67 26.05 23.13 2.80 30.82 28.05 2.97 34.87 34.87 3.07 43.01 43.01 3.17 42.03 42.03 3.33
Heating Indoor Model Capacity Power Furnace Model
*FC4DN(F,B)036 1.00 1.00
FC4DN(F,B)042 0.97 0.95
FK4DNF002 1.03 1.03
FK4DNF003 1.01 1.00
FK4DNF005 0.87 0.89
CAR**3614A** 0.98 1.00 315(A,J)AV036070
CNRH*3617A** 1.00 1.03 315(A,J)AV036070
CNRH*4221A** 1.00 1.00 315(A,J)AV036070
CSRH*3612A** 0.99 0.99 315(A,J)AV036070
CSRH*4212A** 0.98 0.97 315(A,J)AV036070
CAR**3617A** 1.00 1.01 315(A,J)AV048090
CNRH*3617A** 1.00 1.02 315(A,J)AV048090
CNRH*4221A** 0.99 0.98 315(A,J)AV048090
CNRV*3617A** 1.00 1.02 315(A,J)AV048090
CSRH*3612A** 0.99 0.97 315(A,J)AV048090
CSRH*4212A** 0.98 0.96 315(A,J)AV048090
CAR**3621A** 1.00 1.01 315(A,J)AV060110
CAR**4221A** 0.99 0.99 315(A,J)AV060110
CNRH*3617A** 1.00 1.02 315(A,J)AV060110
CNRH*4221A** 0.99 0.97 315(A,J)AV060110
CNRV*3621A** 1.01 1.02 315(A,J)AV060110
CNRV*4221A** 0.99 0.97 315(A,J)AV060110
CSRH*3612A** 0.98 0.97 315(A,J)AV060110
CSRH*4212A** 0.97 0.95 315(A,J)AV060110
CAR**4224A** 0.99 0.98 315(A,J)AV066135
CNRH*3617A** 1.00 1.02 315(A,J)AV066135
CNRH*4221A** 0.99 0.97 315(A,J)AV066135
CSRH*3612A** 0.98 0.97 315(A,J)AV066135
CSRH*4212A** 0.97 0.95 315(A,J)AV066135
CAR**4224A** 0.99 0.97 315(A,J)AV066155
CNRH*3617A** 1.00 1.01 315(A,J)AV066155
CNRH*4221A** 0.99 0.96 315(A,J)AV066155
CSRH*3612A** 0.98 0.96 315(A,J)AV066155
CSRH*4212A** 0.97 0.94 315(A,J)AV066155
CAR**4224A** 1.00 1.01 355AAV042040
CNRH*3617A** 1.01 1.04 355AAV042040
CNRH*4221A** 1.00 1.00 355AAV042040
CSRH*3612A** 0.99 0.99 355AAV042040
CSRH*4212A** 0.98 0.98 355AAV042040
CAR**3617A** 1.01 1.02 355AAV042060
CNRH*3617A** 1.01 1.03 355AAV042060
CNRH*4221A** 0.99 0.99 355AAV042060
CNRV*3617A** 1.01 1.03 355AAV042060
CSRH*3612A** 0.99 0.98 355AAV042060
CSRH*4212A** 0.98 0.96 355AAV042060
Heating Indoor Model Capacity Power Furnace Model
CAR**3621A** 1.01 1.03 355AAV042080
CAR**4221A** 1.00 1.01 355AAV042080
CNRH*3617A** 1.01 1.05 355AAV042080
CNRH*4221A** 1.00 1.00 355AAV042080
CNRV*3621A** 1.01 1.04 355AAV042080
CNRV*4221A** 1.00 1.00 355AAV042080
CSRH*3612A** 0.99 1.00 355AAV042080
CSRH*4212A** 0.98 0.98 355AAV042080
CAR**3621A** 1.01 1.02 355AAV060080
CAR**4221A** 1.00 1.00 355AAV060080
CNRH*3617A** 1.01 1.03 355AAV060080
CNRH*4221A** 0.99 0.99 355AAV060080
CNRV*3621A** 1.01 1.03 355AAV060080
CNRV*4221A** 0.99 0.99 355AAV060080
CSRH*3612A** 0.99 0.98 355AAV060080
CSRH*4212A** 0.98 0.97 355AAV060080
CAR**3621A** 1.00 1.01 355AAV060100
CAR**4221A** 0.99 0.99 355AAV060100
CNRH*3617A** 1.01 1.03 355AAV060100
CNRH*4221A** 0.99 0.98 355AAV060100
CNRV*3621A** 1.01 1.03 355AAV060100
CNRV*4221A** 0.99 0.98 355AAV060100
CSRH*3612A** 0.99 0.98 355AAV060100
CSRH*4212A** 0.98 0.96 355AAV060100
CAR**4224A** 0.99 0.99 355AAV060120
CNRH*3617A** 1.01 1.03 355AAV060120
CNRH*4221A** 0.99 0.98 355AAV060120
CSRH*3612A** 0.99 0.98 355AAV060120
CSRH*4212A** 0.98 0.96 355AAV060120
See notes on pg. 31
213R

Bryant LEGACY 213R Specifications

Operating Environment

leak test pressure	217 psig
pressure test	450 psig
salt spray test duration	500 hr

Power

voltage (single phase)	v
voltage limits (single phase)	_ v to v
voltage (three phase)	v
voltage limits (three phase)	_ v to ___ v
control circuit voltage	24 v

Weight and Dimensions

nominal tons	1-1/2 to 5 tons
