3
569J*12F only). Copy the unit’s Model Number from the
unit’s dataplate into the open line in the header above Fig. 1 to
facilitate this step.
Matching 569J Model to Evaporator Coil
The Model 569J***A/B/G/H is a single-circuit unit design, re-
quiring one set of refrigeration piping. This model can be con-
nected to an evaporator coil with one circuit or with two cir-
cuits (by manifolding the evaporator connections into a single
piping system).
The Model 569J***D/E/F is a dual-circuit unit design that re-
quires two sets of refrigeration piping between the outdoor unit
and the evaporator coil (or coils). This model can only be connect-
ed to an evaporator coil that has two refrigeration circuits (or to
two separate evaporator coils). The Model 569J***D/E/F
CANNOT be connected to a single-circuit evaporator coil. The
Model 569J***D/E/F CANNOT be field-converted to a single-
circuit design. See Table 3.
Table 3 — Evaporator Coil Connections
Before unpacking this new 569J model, compare the evapora-
tor coil design to the 569J model.
General
For unit dimensions see Fig. 3. For corner weights and dimen-
sions see Table 4. For physical data see Tables 5 and 6.
Fig. 1 — Model Number Nomenclature
Fig. 2 — Serial Number Nomenclature
EVAPORATOR COIL
HAS
CONNECT TO
MODEL
NOTES
Single Circuit 569J***A/B/G/H —
Two Circuits
569J***A/B/G/H
Manifold evaporator
circuits into single piping
system.
569J***D/E/F
Use two separate piping
systems
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
569JE12F000A00A0A
Model Type
569J = Bryant Condensing Unit
Puron
®
R–410A Refrigerant
Packaging
A=Standard
B=LTL
Refrigerant Circuit
A = Single Circuit
B = Single Circuit with Low Ambient Controller
D = Dual Circuit
E = Dual Circuit with Low Ambient Controller
F = Dual Circuit with Hot Gas Bypass (569J* size 12 only)
G = Single Circuit, Two Stage (569J* size 07 and 08 only)
H = Single Circuit, Two Stage with Low Ambient Controller
(569J* size 07 and 08 only)
Electrical Options
A = None
C = Non-Fused Disconnect
Service Options
0 = None
1 = Unpowered Convenience Outlet
2 = Powered Convenience Outlet
Base Unit Controls
0 = Electro-Mechanical Controls
Not Used
0 = Not Used
Not Used
0 = Not Used
Not Used
0 = Not Used
Not Used
0 = Not Used
Voltage
E = 460/3/60
P = 208 / 230/3/60
T = 575/3/60
Nominal Tonnage
07 = 6 Tons
08 = 7.5 Tons
12 = 10 Tons
14 = 12.5 Tons
Coil Options
RTPF
A = Al/Cu Standard
B = Pre Coated Al/Cu
C = E-Coated Al/Cu
E = Cu/CuM=Al/Cu Standard with Louvered Hail Guard
N = Pre Coated Al/Cu with Louvered Hail Guard
P = E-Coated Al/Cu with Louvered Hail Guard
R = Cu/Cu with Louvered Hail Guard
Position
Enter this unit’s
Model Number
Example
051
5912345
123
45678910
DESIGNATESPOSITION
Week of manufacture (fiscal calander)
Manufacturing location5
rebmunecneuqeS
Year of manufacture (”19” = 2019)
1−2
6−10
3−4
POSITION NUMBER
TYPICAL
