Table 10: Parts list with 4-speed motor (PSC)
ITEM PART # DESCRIPTION COMMENTS
1 B03409 HEAT EXCHANGER Heat exchanger only
2 J06L002 SEAL STRIP, 1/4 x 1/8 x 25'
3 B03429 WIRE CHANNEL, INT.
4 B03420-01 FRONT PANEL ASSEMBLY Panel, insulation and labels included
5 B03444 FRONT PANEL INSULATION
6 B03450-01 BAFFLE, LATERAL
7 B03426-01 SIDE PANEL ASSEMBLY (RIGHT) Panel, insulation and baffle included
8 B03473 SIDE PANEL INSULATION
9 L04J001 CABLE CLAMP, 9/16" WHITE
10 F06F015 WASHER, ZINC 1 7/16"
11 Z99F061 OBSERVATION PORT
12 L04I013 STRAIN RELIEF BUSHING
13 B03448 WIRE CHANNEL (BVSO/SWITCH)
14 B03455-01 ELECTRICAL KIT, BVSO INT.
15 L07F003 ROCKER SWITCH, SPST
16 R02R006 HIGH LIMIT 36T01B7 150-20F, 7"
17 B03454 ELECTRICAL KIT, BURNER
18 B03453 ELECTRICAL KIT, TT
19 B03472 BAFFLE One baffle included
20 B03416 RADIATOR BAFFLE Item # 52 included
21 F07O001 FLANGE NUT, HEXAGONAL 3/8-16NC BRASS
22 F07F011
HEX NUT 3/8-16NC ZINC
23 Z99F050 HANDLE , RECESSED BLACK
24 B03419 BLOWER DOOR ASSEMBLY Door and labels included
25 B03439 COVER, ELECTRICAL BOX
26 B03535-01 REPLACEMENT BLOWER ASSEMBLY Blower, motor and capacitor included
27 Z06G001 BLOCKED VENT SHUT-OFF BVSO-225
28 B03118-01 ELECTRICAL KIT, BVSO EXT.
29 B03470 FLOOR
30 B03426-02 SIDE PANEL ASSEMBLY (LEFT) Panel, insulation and baffle included
31 B03480 FILTER RACK KIT
32 B03450-02 LATERAL BAFFLE
33 B30513 BLOWER SLIDE One slide included
34 B03441 BLOWER DIVIDER
35 B03451 REAR BAFFLE
36 B03427 REAR PANEL ASSEMBLY Panel, insulation and baffles included
37 B03471 REAR PANEL INSULATION
38 B03457-01 ELECTRICAL KIT, BLOWER
39 L01I001 CAPACITOR 5MF
40 B01024 CAPACITOR HOLDER
41 B03456 ELECTRICAL KIT, BOARD
42A R99G004 ELECTRONIC BOARD, UTEC 1158-110
42B R99G002 ELECTRONIC BOARD, HONEYWELL ST9103A
43 B03440 ELECTRICAL BOX
44 L01F009 TRANSFORMER, 120-24Volt, 40VA
45 B03438 SUPPORT, ELECTRONICS BOX
46 R02R007 HIGH LIMIT, 120-20F, 1.75''
47 B03437 BLOWER SLIDE One slide included
48 B03720-02 BLOWER, 100-8R DD 0,50 PP Housing, wheel and label only
49 B01888 MOTOR SUPPORT ASSEMBLY Legs, band and hardware included
50 B01890-01 MOTOR ASSEMBLY, 1/3 HP Complete with legs
51 B03428 SMOKE OUTLET GASKET
DOWNFLOW BASE B03464-01
HORIZONTAL FLOW BASE B00488-01
VENT TERMINAL KIT 4'' For sealed combustion
4" INSULATED FLEX VENT 10ft For sealed combustion
4" INSULATED FLEX VENT 20ft For sealed combustion
BECKETT NX BURNER (0.50-60A NOZZLE)
RIELLO 40-F3 BURNER (0.50-70A NOZZLE)
RIELLO 40-BF3 BURNER (0.50-70A NOZZLE) For sealed combustion
N01F055
KLABR201RLO
N01J050
KLABR0101BEC
N01F054
KLABR101RLO
IFV098-10
KLAFV0101DET
IFV098-20
KLAFV0201DET
HFB-101
KLASB0701DET
VTK-098
KLAVT0101DET
ACCESSORIES
DFB-102
KLASB0801DET
B50064H
