Bryant PLUS 90X 353AAV - Electrical Data; Electrical Specifications; Typical Wiring Schematic

19
ELECTRICAL DATA
UNIT SIZE 036040 036060 036080 048080 060100 060120
U N I T V O LT S --- H E R T Z --- P H A S E 1 1 5 --- 6 0 --- 1 1 1 5 --- 6 0 --- 1 1 1 5 --- 6 0 --- 1 1 1 5 --- 6 0 --- 1 1 1 5 --- 6 0 --- 1 1 1 5 --- 6 0 --- 1
MAXIMUM UNIT AMPS 8 9.4 9.4 9.6 12.1 12.1
UNIT AMPACITY 10.8 12.5 12.5 12.8 15.9 15.9
MINIMUM WIRE SIZE 14 14 14 14 12 12
MAXIMUM WIRE LENGTH --- FT (M) 34 (10.3) 29 (8.8) 29 (8.8) 29 (8.8) 36 (10.9) 36 (10.9)
MAXIMUM FUSE OR CKT BKR (Amps)** 15 15 15 15 20 20
TRANSFORMER (24v) 40va
EXTERNAL CONTROL
POWER AVAILABLE
HEATING 12va
COOLING 21va
AIR CONDITIONING BLOWER RELAY 24v Standard
TYPICAL WIRING SCHEMATIC
115-V FIELD-
SUPPLIED
DISCONNECT
AUXILIARY
J-BOX
24-V
TERMINAL
BLOCK
THREE-WIRE
HEATING-ONLY
FIVE WIRE
NOTE 1
NOTE 2
FIELD-SUPPLIED
DISCONNECT
CONDENSING
UNIT
TWO
WIRE
FURNACE
C
O
N
T
R
O
L
R
G
COM
WCR GY
GND
GND
FIELD 24-V WIRING
FIELD 115-, 208/230-, 460-V WIRING
FACTORY 24-V WIRING
FACTORY 115-V WIRING
208/230- OR
460-V
THREE
PHASE
208/230-V
SINGLE
PHASE
BLOWER DOOR SWITCH
WHT
BLK
WHT
BLK
NOTES: Connect Y-terminal in furnace as shown for proper blower operation.
Some thermostats require a "C" terminal connection as shown.
If any of the original wire, as supplied, must be replaced, use
same type or equivalent wire.
W
Y/Y2
GND
THERMOSTAT
TERMINALS
1.
2.
3.
A99440
353AAV
