Bryant PLUS 90X 353AAV - Typical Installations

20
TYPICAL INSTALLATIONS
COMBUSTION AIR PIPE
(DIRECT VENT/2-PIPE APPLICATION)
A/C COIL
OUTDOOR UNIT
VENT PIPE
HUMIDIFIER
GAS-FIRED
WATER HEATER
ELECTRONIC
AIR CLEANER
AIRFLOW
FRONT OF
FURNACE
COMBUSTION
AIR INLET
(NON-DIRECT
1-PIPE APPLICATION)
A05064
Upflow Application
ELECTRONIC
AIR CLEANER
HUMIDIFIER
A/C COIL
VENT
COMBUSTION
AIR (DIRECT VENT/
2 PIPE APPLICATION
OUTDOOR
UNIT
AIRFLOW
FRONT OF
FURNACE
COMBUSTION AIR
INLET (NON-DIRECT
VENT/ 1-PIPE APPLICATION
A05065
Downflow Application
353AAV
