Bryant PLUS 95S - Page 13

13
DOWNFLOW SUBBASE
A97427
Assembled
A88207
Disassembled
LOCATING
TAB
LOCATING
TAB
1
2
3
4
4
3
2
1
B
D
C
A
1
1
/
4
″ TYP
PLENUM
OPENING
FACTORY-SUPPLIED
FIELD-INSTALLED
INSULATION
DIMENSIONS (IN. / MM)
FURNACE
CASING
WIDTH
FURNACE IN DOWNFLOW
APPLICATION
PLENUM OPENING* FLOOR OPENING
HOLE NO.
FOR WIDTH
ADJUSTMENT
A B C D
17--- 1/2 / 444.5
Furnace with or without
Cased Coil Assembly or Coil
Box
15--- 1/8 /
384.2
19 / 482.6
16--- 3/4 /
425.5
20--- 3/8 /
517.5
3
21 / 533.4
Furnace with or without
Cased Coil Assembly or Coil
Box
18--- 5/8 /
396.4
19 / 482.6
20--- 1/4 /
514.4
20--- 3/8 /
517.5
2
24--- 1/2 / 622.3
Furnace with or without
Cased Coil Assembly or Coil
Box
2 2 --- ‘ / 8 /
562.0
19 / 482.6
23--- 3/4 /
603.3
20--- 3/8 /
517.5
1
*The plenum should be constructed 1/4--- in. smaller in width and depth than the plenum dimensions shown above.
MEDIA FILTER CABINET
A
23
5
/
8 "
23
3
/
8 "
Furnace Side
23
3
/
4 "
Centerline Screw Slots
25
5
/
8 "
Duct Side
24
3
/
8 "
Opening with Flanges Bent
23
1
/
8 "
Opening
5
3
/
4 "
gninepO B
A07803
DIMENSIONS (IN. / MM)
MEDIA FILTER CABINET A B SHIPPED WITH SIZES
16 / 406.4 17 / 432.8 16 / 406.4 042060
20 / 508.0 21 / 533.4 20 / 508 042080, 060080, 060100
24 / 609.6 25 / 635.0 24 / 609.6 060100
355CAV
