TYPICAL INSTALLATIONS (CONTINUED)
COMBUSTION–AIR PIPE
ELECTRONIC
A
IR CLEANER
FURNACE
CONDENSATE
DRAIN
REFRIGERATION
PIPING
AIR CONDITIONING
COIL
AIRFLOW
VENT PIPE
FRONT OF FURNACE
DIRECT VENT/2-PIPE APPLICATION)
OPTIONAL VENTILATED COMBUSTION
AIR APPLICATION
A07800
Attic --- Horizontal Application
COMBUSTION– AIR PIPE
(DIRECT VENT/2-PIPE
APPLICATION)
VENT
PIPE
ELECTRONIC
AIR CLEANER
FURNACE CONDENSATE
DRAIN
AIRFLOW
IR CONDITIONING
COIL
REFRIGERATION
PIPING
FRONT OF
FURNACE
OPTIONAL VENTILATED
COMBUSTION AIR INTAKE
A07801
Crawlspace --- Horizontal Application
