Manual EVoBASIC v.7 73 / 80
Go to the "pH" menu and select "Manual". Keeping the "OK" button
pressed, the pump will be running. Keep the pump running with the "OK"
button until the liquid has passed throughout the tube until injection.
4.1.6.7- Acid – Alkaline
Access the configuration menu of the equipment to pass the pH control
from acid to alkaline. To do this, press "OK" in the main screen, in
configuration "S" press button until reaching the ACID line. Press "OK"
and the letter "N" will appear with the arrow . Select “S” to remain in
the ALKALI screen.
Note: Password “1234” is required to modify this
function.
4.1.6.8- Automatic shutdown and error message.
If the acid pump shuts down and the message "pH ERROR" appears, the
pump has been operating too long without the pH value lowering to the
required level. The causes could be:
-There is no acid.
-Problem in the pump or in the acid duct.
-The probe or probe cable are damaged.
NOTE: to cancel the error alarm, press the "OK" button
4.1.7- Relay
The EVO series equipment has a programmable auxiliary relay that can
be used to control the filtering pump, swimming pool lighting and others
features See pages 23 and 24 of this manual for further details.
4.1.7.1- Start/Stop
This manually turns the relay on / off.
