Manual EVoBASIC v.7 54 / 80
3.2.5- NTC/1 kit (OPTIONAL)
The temperature probe kit enables you to take a reading of the water
temperature. Once the probe has been connected, the temperature will
be displayed in the main screen.
By installing this kit, you will also be able to use the semi-automatic
control mode. More details on this mode can be found on the 4.2 chapter
in this manual.
1-NTC prove
2- Probe-Holder
3-Flange
3.2.6- Measurement of salt concentration in the TOUCHEVO systems
When an NTC/1 probe kit is installed in the chlorinator, the salt
concentration measurement feature is enabled automatically.
This parameter is calculated based on the values of electrical current and
voltage in the electrolysis cell, together with the water temperature.
The result is displayed at the bottom of the main screen, as shown in the
image below.
Please take note of the following considerations regarding the indirect
measurement of salt concentration:
The salt calculation will appear on screen only if an NTC/1 kit is installed,
since this kit is in charge measuring the water temperature, necessary
for the calculation.
This value gets updated once the chlorine production percentage reaches
100%.
