Contents
14.0 Modes of Operation 21
14.1 Mono Three Way with Extra Full Range
Buffered Output 21
14.2 Operating a Sub-Woofer system from an
Effects Send 21
14.3 Mono Low between separate units 21
15.0 Limiter Adjustment 22
Adjustment for A 22
Adjustment for B 22
16.0 Phase Adjustment 24
17.0 System Diagrams and Descriptions25
17.1 Full unit 25
17.2 15Hz Subsonic Filter Change 25
18.0 Filters and Frequency Tables 27
18.1 Standard Filters 27
18.2 Full Range Frequency Card 27
19.0 BSS Supported Options 30
19.1 Output Balancing 30
19.2 Security Cover 30
20.0 FDS-360 Equalisation Options 31
20.1 Introduction 31
20.2 FDS-360D Installation 31
20.3 Circuit Description 31
20.4 Filter Design 33
20.5 Application Notes 35
20.6 Application of the FDS-360D to a system 36
20.7 FDS-360 E Installation 38
21.0 Electronic/Chassis Earth Link 39
22.0 Transient Suppressor Replacement 39
23.0 Troubleshooting 40
24.0 Glossary 41
25.0 Specifications 44
26.0 Warranty Information 45
Index 49
User Notes 51
Spare Parts Information
