Quick Reference Guide QRG
Quick Reference Guide EDV no.: MD.341.01.01
ekr 500 Plus with CLS Pro 600 Issue Date: 31.03.2009
Contents
1 General information 1
1.1 System overview ................................................................... 1
1.2 Used terms ............................................................................ 1
2 Start-up ekr 500 Plus 3
2.1 Set DIL switches.................................................................... 3
2.2 Start-up of the EMS actuator................................................. 5
2.2.1 Determine sense of motor rotation.........................................5
2.2.2 Determine guiding direction....................................................5
2.2.3 Actuator without position feed back
(EMS 5 / EMS 10 / EMS 16)...................................................5
2.2.3.1 Determine guiding direction for operating mode
Servo-center (OMG 4, OMG 8) 5
2.2.3.2 Adjust gain of the servo-center component
(OMG 4, OMG 8) 6
2.2.4 Actuator with position feed back
(EMS 17, EMS 21, EMS 22)...................................................7
2.2.4.1 Determine guiding direction for operating mode
Servo-center 7
2.2.4.2 Adjust stroke limitation and servo-center position 8
3 Setting up the CLS Pro 600 11
3.1 General................................................................................ 11
3.2 Requirements ...................................................................... 11
3.3 Adjust password level.......................................................... 12
3.4 Configuration ....................................................................... 13
4 Material Setup 15
4.1 at the controller.................................................................... 15
4.2 at the sensor........................................................................ 15
4.3 Edge set-up mode............................................................... 16
4.4 Line setup mode.................................................................. 17
5 Optimise gain 18
