BST ekr 500 Plus - System Overview; Used Terms

Quick Reference Guide QRG
1 General information
1.1 System overview
Use this Quick Reference Guide if the system you use has the
following configuration:
controller ekr 500 Plus
with removed control panel
o
r
controller ekr 500 Plus
with fitted control panel
connector X101
Actuators with
position feed back
EMS 17, EMS 21, EMS 22
Line and contrast sensor
CLS Pro 600
o
r
Actuators without
position feed back
EMS 5, EMS 10, EMS 16
Servo-center
component
OMG 4, OMG 8
Edge sensor
1.2 Used terms
According to BST definition, the following relation applies between
the selection buttons fort he guiding mode and the sensors:
= Sensor 1 (left web edge)
= Sensor 2 (right web edge)
= Sensor 3 (line / contrast scanning)
Quick Reference Guide EDV no.: MD.341.01.01
ekr 500 Plus with CLS Pro 600 Issue Date: 31.03.2009 Page: 1/18
