BT CONVERSE 2100 User Manual

If you experience any problems, please visit www.bt.com/producthelp
5
5
WARNING
Do not place your BT Converse 2100 in the
bathroom or other humid areas.
Other electrical equipment close to your
Converse could have an adverse effect on call
quality. If you experience buzzing during a call
try moving the Converse away from any electrical
equipment that may be nearby.
Location
You need to place your BT Converse 2100 within 3 metres of a telephone socket
so that the cable will reach. Your BT Converse 2100 can be wall mounted,
see ‘Wall mounting your phone’ on page 14.
Setting up
1. Plug the end of the telephone line cord into the telephone wall socket.
2. Check that the dialling Mode switch on the underside of the base is set to
TB for tone dialling with timed break recall.
3. Fit the desk mounting plinth if required by positioning the plinth over the lugs
and pushing it down into place, as shown by the blue arrows.
Your BT Converse 2100 is now ready for use.
Getting started
Dialling mode
If connecting to a switchboard you may need to
adjust the dialling mode setting to P or T using
the Mode switch on the underside of the base.
If in doubt, please consult your service provider.
IMPORTANT
Only use the handset and line cord supplied or
this product may not work.

BT CONVERSE 2100 Specifications

General

Type	Analog telephone
Ringer type	Polyphonic
Handset type	Wired & Wireless handset
Answering machine	No
Number of melodies	3
Maximum indoor range	- m
Microphone frequency	- Hz
Microphone sensitivity	- dB
Operating system installed	-
Warranty period	1 year(s)
Display diagonal	- \
Display resolution	- pixels
Display size (HxV)	- mm
Redialing	Yes
Operating temperature (T-T)	- °C
Operating relative humidity (H-H)	- %
Battery capacity	- mAh
Battery recharge time	- h

Weight and Dimensions

Depth	160 mm
Width	100 mm
Height	220 mm
Weight	570 g
