BÜCHI Labortechnik AG Installation | 5
Operation Manual Ultrasonic Package 19/34
u Attach the cooling gas onto the connection
marked IN.
u Attach the inlet tube in place with the union
nut.
u Select a suitable type of supply hose. See re-
sistance table of the "Operation Manual B-290
Mini Spray Dryer ".
u Cut approx. 50 mm from the feeding tube.
u Attach the damper to the Y-piece.
u Attach the tube piece to the Y-piece.
u Attach the feeding tube to the Y-piece.
