Buchi Vac V-500 - 9 Appendix; Technical Data; Materials Used

31
BÜCHI Vac V-500/V-501/V-502/V-503 9 Appendix
9 Appendix
9.1 Technical data
V-500 V-501 / V-502 / V-503
Measurements (L x B x H) 150 x 294 x 236 mm 230 x 420 x 400 mm
Weight 8 kg 9-11 kg
Electrical supply 230 VAC 50 Hz, +/-10 % 230 VAC 50 Hz, +/-10 %
220 VAC 60 Hz, +/-10 % 220 VAC 60 Hz, +/-10 %
120 VAC 50/60 Hz,+/-10 % 120 VAC 50/60 Hz, +/-10 %
100 VAC 50/60 Hz,+/-10 % 100 VAC 50/60 Hz, +/-10 %
Power consumption 240 W 240 W
Surrounding temperature 5 - 40 °C 5 - 40 °C
Environmental conditions for indoor use only, altitude up to 2000 m.
maximum relativ humidity 80% for temperatures up to 30°C
Final vacuum possible < 10 mbar < 10 mbar
Pumping volume 1.6 m
3
/h 1.6 m
3
/h
Relative humidity max. 80% max. 80%
Excess voltage category II II
Degree of contamination 2 2
V-800 see Operating instructions V-800
Connection 24V-Switchbox DC
24V / 30 mA
Table 10: Technical data
Description Material Material code
Pump heads Glas 3.3
Housing Aluminium
Housing cover PBT
Diaphragms PTFE / rubber
Valve plate PEEK
Valve head PEEK
Vacuum hoses PTFE / rubber
Gasket rings valves ETFE
Diaphragms, valve unit Perfluorelastomer
Gasket secondary condenser / valve unit PTFE / PEEK
Table 11: Materials
9.2 Materials used
