Modules for Logamatic 4000 control panels - We reserve the right to make technical modifications.
13
Module installation for Logamatic 43xx controls 3
3.3 Installation
z Loosen both screws (Æ Fig. 3, [1] und [3]) on the top side of the
appliance.
z Remove terminal cover (Æ Fig. 3, [2]).
Fig. 3 Removing covers
WARNING!
RISK OF LIFE
due to electrical current when the control panel is open.
z Before opening the control panel:
isolate all poles of the power supply and secure against
accidental reconnection.
