6
Operating instructions Logatop BE-A blue burner • Issue 2
012/11
We reserve the right to make any changes due to technical modifications.
Start-up instructions3
3.1 Operating Instructions
STOP! First read the safety instructions on
Î Page 5 of this manual.
1. Set thermostat to the lowest value.
2. Disconnect the heating system from the power
supply.
3. Shut off main gas supply valve.
4. Remove safety screws from the left and right side
panels, then lift the front panel of the boiler and pull
it forward.
5. Turn gas valve ON/OFF button clockwise to OFF
position. Do not use force.
6. Wait five (5) minutes until all gas residues have
dissipated. Check whether there is still any smell of
gas, including at floor level. If there is a gas odor:
STOP! Follow instructions in section "B" of the safety
instructions in (Î Chapter 3, Page 5). If there is no
sign of a gas odor, continue with the next step.
7. Turn gas valve ON/OFF switch counterclockwise to
ON position. Do not use force.
8. Attach front panel of boiler (Î Fig. 2).
9. Open main gas supply valve.
10. Switch on electric power to heating system.
11. Set thermostat to desired room temperature.
12. If the heating system does not start operating, follow
the instructions for "switching off gas supply to
boiler" (Î Chapter 3.2, Page 7) and inform your
customer service technician or your gas company.
Fig. 2 Removing front panel of boiler
1 Screws
2 Boiler front panel
1
2
1
Fig. 3 Gas fitting
1 ON/OFF button (at ON position)
1
USER NOTE
This unit is fitted with an igniter that
automatically starts the ignition burner.
Do not attempt to ignite it manually.
