4 Scope of delivery
The boiler can be delivered either as a pre-assembled
block or in loose sections.
B After delivery, check all packaging for perfect
condition.
B Check the delivery for completeness.
4.1 Logano G615 – Delivery as a pre-
assembled block
4.2 Logano G615 – Delivery in loose
sections
5 Transporting the boiler
Use suitable equipment to transport the individual boiler
sections (delivery as loose sections) and other individual
parts.
Component Qty Packaging
Boiler heat exchanger 1 Pallet
Fittings 1 Crate
Assembly parts 1 Crate
Jacket pack A 1 Crate
Jacket pack B 1 Crate
Thermal insulation 1 Foil pouch
Tab. 5 Scope of delivery (block delivery)
Component Qty Packaging
Front, rear, intermediate
section with top supply
connection and burner door
1 Pallet
Central sections (depending
on boiler size)
2– 5 Pallet
Fittings basic unit, 9 – 16
pieces
1Crate
Additional fittings (content
depends on boiler size)
1 Crate
Assembly parts 1 Crate
Jacket pack A 1 Crate
Jacket pack B 1 Crate
Thermal insulation 1 Foil pouch
Tie rods set with spring
packages
Tab. 6 Scope of supply (loose sections)
WARNING: Risk of injury from improperly
secured boiler sections.
B Use only suitable means of transportation
when handling the boiler sections, e.g. a
sack truck with strap or heavy duty dolly.
B Secure the individual boiler sections to
prevent them from sliding off when
transporting them.
NOTICE: Risk of system damage from
impacts.
B The standard delivery of the Logano G615
oil/gas-fired boiler contains components
that are sensitive to shock.
B During handling protect all electronic and
other components against impact.
B Please observe the transport instructions
on the packaging.
NOTICE: Risk of system damage from
contamination.
B If you intend to keep the boiler in storage
once it has been assembled, observe the
following:
B Protect the boiler connections against
contamination by sealing them off or
covering them.
Dispose of packaging in an environmentally
responsible manner.
