3
Specifications
Logano G615 - Subject to technical modifications
11
3 Specifications
The technical data provides information about the output
profile of the Logano G615 .
Fig. 3 Connections and dimensions
AA Flue gas spillage
EL Drain valve (Rp ¾)
1)
L
K
Boiler heat exchanger length
L
G
Overall boiler length
RK Return connection on the boiler
2)
VK Supply connection on the boiler
3)
(1390 mm)
54 23/32"
EL
RK
6 720 642 625-02.1o
L
G
VK
L
K
(125 mm)
4 59/64"
L
F
T
(750 mm)
29 17/32"
14 11/64"
(360 mm)
AA
(1826 mm)
71 57/64"
(1596 mm)
62 27/32"
(1281 mm)
50 7/16"
(350 mm)
13 25/32"
6"
(150 mm)
1) With the drain valve (EL), you may only drain the system, not fill it.
2) The filling of the boiler and the system must be undertaken on a
separate connector on the return line.
3) The flange corresponds to the order reduced to 212 (DN100), 176
(DN80) or 149 (DN65).
