Parts List 13
53
We reserve the right to make any changes due to technical modifications!
Installation, Operation and Maintenance Manual Sealed Combustion Gas Boiler Logano GA244 • Issue 02/2004
Buderus Heiztechnik GmbH • http://www.heiztechnik.buderus.de
Table 16 Measuring line set
Measuring Line - Set (Fig. 42)
Item.
No.
Part description
Buderus
Part number
Model 37
Quantity
Model 44
Quantity
Model 53
Quantity
Model 62
Quantity
10 Measuring line set CE244 6302- 5822 5822 5822 5822
The measuring line set contains the following components:
20 Pressure measuring orifice G1/8" (DIN288-1) 0548- 1194 1194 1194 1194
30 Gasket ringDIN7603 A 10x13,5x1,5 Cu 6301- 5874 5874 5874 5874
40 Hex.-nut G1/8" 2 2 2 2
50 Pressure measuring orifice G1/8" 1 1 1 1
60 Silicone hose 3x1,5x120mm 1 1 1 1
70 Pressure measuring orifice 394537 1 1 1 1
