Parts List13
Table 18 Burner tray assembly
Burner Tray Assembly (Fig. 44)
Item.
No.
Part description
Buderus
Part number
Model 37
Quantity
Model 44
Quantity
Model 53
Quantity
Model 62
Quantity
10 Burner tray assembly CE244 compl. 6302- 5795 5795 5796 5797
20 Gasket for burner tray assembly Gasket set
30 Secondary air guide plate
40 Lens screw DIN7985-M4x20-5.8-A3K 0588- 3286 3286 3286 3286
50 Flame roll-out switch 377Grad f 0047- 1336 1336 1336 1336
60
Screw DIN7500 CE M5x12 CombiTorx
15 pieces/set
6302- 8938 8938 8938 8938
70 Burner tray cover plate CE244 5Gld compl. "US" 6302- 5808 5808 5809 5810
80 Bottom - gasket for burner tray cover plate Gasket set
90 Top - gasket for burner tray cover plate Gasket set
100 Observation port compl. 0710- 0256 0256 0256 0256
110 Screw St3,9x9,5 A3T 0594- 7754 7754 7754 7754
120
Gasket - Set for burner tray assembly CE244
5 section compl.
6302- 5925 5925 5926 5927
130 Clue Elastosil E 41 in 90ml tube 6301- 1270 1270 1270 1270
