9.3 Checklist
z Servicing work carried out must be marked with an "X"
in the appropriate column and confirmed by signing and
dating the box underneath with the matching number.
z Servicing work on the burner and boiler must be carried
out in accordance with the relevant servicing instruc-
tions.
Heating system 01 02 03 04 05 06 07 08
1 Isolate heating system from power supply
2 Close main gas isolating valve
3 Disconnect gas pipe from burner
4 Remove front boiler panels, open burner door (Fig. 24, page 23)
5 Remove baffle plate (Fig. 26, page 27)
6 Unscrew neutralizer drain hose (condensate outlet) (Fig. 23, page 23)
7 Inspect/clean combustion chamber
8 Inspect/clean secondary heat exchange pipes
9 Flush out condensate outlet (trap) (Fig. 23, page 23)
10 Inspect/clean flue box
11 Inspect/replace boiler door seal
12 Inspect/replace silicon seal on baffle plate
13 Screw drain hose back onto condensate outlet
14 Refit and secure baffle plate, refit outer casing panels
15
Pour water approx. 3 gal (10 liters) into heat exchanger through combustion
chamber
16 Close burner door and screw down with bolts
17 Reconnect gas pipe to burner
18 Check gas-carrying components for leaks
19 Check flue pipe for leaks
20 Check function of safety devices
21 Check function of control devices
22 Start up heating system according to operating instructions
23
24
For details of servicing the neutralizer unit, refer to the separate instructions (supplied with neutralizer unit)
