Reinstalling the Extended Rear
Convenience Center
1. Make sure that all items have been removed
from the rear of the vehicle.
2. Remove the carpeted mat from the vehicle.
3. Lift the forward bin into the back of the
vehicle. Place the mounting brackets onto the
forward mounting bolts on the floor of the
vehicle.
4. Put the nuts back onto the mounting bolts and
tighten.
5. Lift the rear bin into the back of the vehicle.
Place the rear bin over the center T-shaped
wall on the forward bin. Push down to secure.
Align the rear bin over the rear mounting bolts.
6. Put the nuts back onto the mounting bolts and
tighten.
7. Push and pull on the rear storage system to
make sure that it is locked into place properly.
167
