5. Disconnect the electrical connector by
pulling back on the locking tab, located on
the electrical connector, to separate the
two connectors.
6. Turn the bulb socket
one-quarter of a turn
clockwise.
7. Pull the bulb assembly out from the lamp
housing.
8. Unhook the electrical connector by lifting up
the gray tabs and separate the connector
from the bulb base.
9. Install the appropriate new bulb into the
electrical connector. Push the bulb firmly
enough so that the gray tabs hook over the
tab on the bulb.
10. Put the bulb assembly back into the lamp
housing and turn the bulb socket one-quarter
of a turn counterclockwise.
400
