Fuse Usage
39 Engine Cooling Fan 1
40
Main Battery Fuse for Retained
Accessory Power Relay and
Accessory Relay
41
Main Battery Fuse for Heated Seats,
Air Conditioning, Defogger
44
Main Battery Fuse for Power
Outlets, Level Control, Power Seats,
Mirrors, and Body Computer
46
Main Battery Fuse for Climate
Control Blower and Ignition 3 Relay
47
Main Battery Fuse for Ignition
Switch, Radio, Heads-Up Display
(HUD), Remote Keyless Entry
(RKE), Instrument Cluster, Air
Conditioning, and Body Computer
70
§
Diode for Air Conditioning
Compressor Clutch
§ 71
Diode for Ignition
Relay Usage
49 Horn
50 Fuel Pump
51 Air Conditioning Clutch
52 Daytime Running Lamps (DRL)
53 Low-Beam Headlamps
54 Parking Lamps
55 High-Beam Headlamps
56 Fog Lamps
57 Starter Relay
58 Cooling Fan Series/Parallel
59 Powertrain
60 Cooling Fan 2
61 Cooling Fan 1
62 Ignition
468
