10
042319
Filling Soluble Hoppers
1. Remove packing material from on top of the powder hoppers.
2. Remove powder hoppers by lifting the front of the powder
hopper until the peg on the bottom of the hopper clears the
hole in the mounting plate (see Figure 1). Then pull the
hopper forward to remove.
3. Set the hoppers on the counter, and push the elbows up
(see Figure 2) to close the chutes.
Figure 1
Figure 2
Figure 3
Figure 3
To Next Page
