Bunn Crescendo Series User Manual

6
042319
1. Remove drip tray and cover from the parts box. Assemble the cover to the drip tray, then slide under
the front door of the machine, engaging the rear of the drip tray into the opening in the lower front of
the machine.
2. Remove the espresso brew group from the parts box.
3. Slide tube onto elbow fitting on upper left side of
espresso group head as shown in Figure 1.
4. Place groove on lower front of group head over
mounting bar on espresso drive as shown
in Figure 2.
Figure 1
P4375
Figure 2
P4376
Groove
Mounting
Bar
INITIAL SET-UP

Bunn Crescendo Series Specifications

General

Beverage Options	Coffee
Grinder	No
Voltage	120 V
NSF Listed	Yes
Material	Stainless Steel
Phase	1
