Bunn Crescendo Series - Page 7

7
042319
6. Rotate the top of group head toward rear of machine until
it snaps into place as shown in Figure 3.
Figure 3
P4377
7. Slide red lock to the right until it snaps into place as
shown in Figure 4.
Figure 4
P4378
8. Install group head tube into quick connect fitting on
bottom of espresso drive, insuring that the tube is
fully inserted as shown in Figure 5.
Figure 5
P4379
Brew Tube
Connection
INITIAL SET-UP - continued
