Bunn IMIX-5 Illustrated Parts Catalog

ITEM PART NO. QTY. DESCRIPTION
21
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
     •IMIX-4Models
     ••IMIX-5Models
   • ••
1 26369.1000 2 1 Plug (Includes item 2)
2 24733.0011 5 6 O-Ring
3 39285.1001 4 5 Valve, Liquid Dispense 120V (Includes item 2)
39285.1002 4 5 Valve, Liquid Dispense 230V (Includes item 2)
39316.1001 - 1 Valve, Liquid Dispense 120V (Includes item 2)(Models with Hot Water Dispense)
01326.0000 4 5 Screw, Truss Head #10-32 x .25"
4 28526.0027* 4 5 Tube, Silicone .312" ID x 16.5" (Order item 10)(One add'l with Hot Water Dispense)
5 21801.0002 4 5 Tube, .375" OD x 1.50" (One add'l with Hot Water Dispense)
6 12422.0001 4 5 Clamp, Hose .59"/.66" ID (One add'l with Hot Water Dispense)
7 25803.0000 4 5 Water Inlet, Mixing Chamber (One add'l with Hot Water Dispense)
8 37970.0000 5 6 Grommet
9 32341.0000 - 1 Tube, Hot Water Dispense (Models with Hot Water Dispense)
10 28526.1001 - - Tube, Silicone .312" I.D. x .438" O.D. x 36"
28526.1002 - - Tube, Silicone .312" I.D. x .438" O.D. x 60"
28526.1003 - - Tube, Silicone .312" I.D. x .438" O.D. x 120"
DISPENSE VALVES AND LINES
Not
Illustrated
37259 091007

Bunn IMIX-5 Specifications

General

Model	IMIX-5
Category	Coffee Maker
Manufacturer	Bunn
Number of Hoppers	5
Hopper Capacity	5 lb (2.27 kg)
Water Tank Capacity	5 gallons
Electrical	120V, 60Hz
Features	Digital display
