Bunn ITCB Series - Setup and Programming; Programming Lockout; Level 1 Programming

Bunn-O-Matic Corporation
7
SetupandProgramming
Accessing and using the brewer’s programming features is done from the front panel and requires no special tools.
The programming menu is accessed through a hidden switch located on the right side of the display. The hidden
switch on the left side will allow you to scroll backwards.
A. Right Hidden Switch: This is used to access the programming mode and is also used to scroll forward through the
function list.
B. Left Hidden Switch: This is used to scroll backwards through the function list.
C. Brew A: This is used to select options that appear on the display during programming.
D. Brew B: This is used to select options that appear on the display during programming.
E. Brew C: This is used to select options that appear on the display during programming.
To exit the programming mode at any time, press and release the ON/OFF button located on the user interface. The
display will return to the main screen.
Programming Lockout
If the programming cannot be access then the programming lockout switch is in the Lock position. The switch is
located on the control board. Remove the top panel, locate the switch and place it into the Unlock position.
Note:PriortoserialnumberICB00007479,thelockoutswitchwillbelocatedonthememorymoduleboard.
Level 1 Programming
Pressthehiddenswitchforonesecondtoaccess.
This function allows the operator to prevent or allow brewing if the water temperature is
less than the Set Ready temperature.
BREW LOCKOUT ?
ON OFFDONE
HALF
FULL
BREW
A
BREW
B
BREW
C
®
ENABLE
ON / OFF
BREW
A
B
C D E
READY TO BREW
WATER TEMP: 200°
MEMORY
LOCK UNLOCK
PROGRAMMING
LOCKOUT SWITCH
P3048
