Bunn LCA-2 - Dispense Valve Units; Hoses, Clamps, and Fittings; Mixing Chamber and Flow Control; Connectors and Tubing

ITEM PART NO. QTY. DESCRIPTION
21
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
DISPENSE VALVES & LINES
34767 032007
(Continued)
1 29576.0000 3 Bracket
00970.0000 3 Nut, Keps #8-32
2 34202.0000 3 Valve, Dispense (Includes item 3)(Refer to item 41)
3 24733.0011 3 O-ring
4 34962.1000 2 Warmer Tube Assy (Includes Warmer Tape w/Leads)
5 20976.0046* 1 Tube, Silicone .375" ID x 5.0" (Order item 36)
6 34644.0000 1 Connector, Barb .375"
7 28526.0002* 1 Tube, Silicone .313" ID x 16.0" (Order item 37)
8 34807.0000 2 Flow Restrictor (Optional for 1.8 oz/sec. flow rate)
9 34689.0000 4 Pin
10 34346.1000 2 Mixing Chamber Assy (Includes items 8, 9, 11 & 12)
01315.0000 4 Screw, Truss Head Sltd. #8-32 x .38"
11 34198.0000 2 Lid
12 34384.0000 2 Snap Cap
13 34727.1000 2 Hose Assy .187" ID (Incl. items 14 - 16)
34727.1001 2 Hose Assy .187" ID x 14.0" Feed End (Incl. items 14 - 16)
34728.1000 2 Hose Assy .125" ID (Incl. items 14 - 16)
14 34727.0000* 4 Hose .187" ID x 9.0"
34727.0001* 2 Hose .187" ID x 14.0"
34728.0000* 4 Hose .125" ID x 9.0"
15 34714.0000 2 Elbow (.187" ID Hose Assy)
34715.0000 2 Elbow (.125" ID Hose Assy)
16 12422.0011 4 Clamp .40/.45" ID (.187" ID Hose Assy)
12422.0007 4 Clamp .31/.34" ID (.125" ID Hose Assy)
17 34726.0001* 2 Tube, Norprene .125" I.D. x 6.0" (Order item 39)
18 05920.0000 2 Clip
19 35057.0000 2 Connector .187"
35057.0001 2 Connector .25"
20 35055.0000 2 Adapter Kit (Includes items 21 - 25)
21 33160.0000 2 Connector
22 11707.0029* 2 Hose, Silicone .25" I.D. x 1.75" (Order item 40)
23 35053.0000 2 Coupling, Reducing
24 12422.0000 2 Clamp .47/.54" I.D.
25 12422.0006 2 Clamp .53/.59" I.D.
26 35056.0000 2 Adapter Kit (Includes items 22,23,24 & 27)
Order item 13
Also order item 37
