ITEM PART NO. QTY. DESCRIPTION
9
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
DOOR ASSEMBLY
34767 032007
- 34284.1000 1 Door Assembly (Includes items 6,7,10,13,14,18 & 21 thru 26)
1 34531.1000 1 Plate w/Decal (Includes item 2)
01321.0001 6 Screw, Truss Head Sltd. #8-32 x 1.25"
2 34809.0001 1 Decal, Maintenance
3 34667.0000 1 Keeper, Door Latch
02336.0000 2 Screw, Truss Head Sltd. #4-40 x .38"
4 34150.0000 1 Seal, Product Cabinet
5 34473.0000 1 Insulation, Door
6 - - - - - - - - 1 Frame, Door (Not Serviced)
7 34334.0000 1 Bracket
01311.0000 2 Screw, Truss Head Sltd. #8-32 x .25"
8 34362.0000 1 Bushing, Lower Hinge
9 - - - - - - - - 1 Lower Door Hinge (See HOUSINGS & PANELS)
10 34741.0000 1 Shoulder Screw #8-32
11 34527.0000 1 Panel
38044.0000 2 Screw, Pan Head #6 48-2
12 26444.0000 1 Bushing, Strain Relief
13 34388.1000 1 Circuit Board, LED
38735.1000 1 Circuit Board, LED (RoHS Compliant)
38044.0000 2 Screw, Pan Head #6 48-2
14 33039.0001 2 Switch, Membrane
15 34340.1000 1 Button Kit (Includes two buttons)
16 34341.1000 2 Stem, Handle
17 34742.0000 2 Spring
18 34387.0000 1 Cover, Switch
19 01219.0000 2 Pin, Faucet Handle
20 33434.1000 1 Handle, Black
33434.1002 1 Handle, Orange
21 34362.0001 1 Bushing, Upper Hinge (Early models only)
22 34283.0000* 1 Door Front (Not serviced separately)
38044.0000 13 Screw, Pan Head #6 48-2
23 34708.0000 1 Decal, Upper Door Wrap
24 34712.0000 1 Decal, Flavor Gard
25 34711.0000 1 Decal, LED Display
Includes item 19
Models LCA-2 & LCC-2
with Standard Controls
(Continued)
Models LCA-2 & LCC-2
with Standard Controls
To Next Page
