Bunn LCA-2 - Page 29

ITEM PART NO. QTY. DESCRIPTION
29
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
ELECTRICAL CONTROLS
23 34393.0000 1 Cable, Ribbon
02327.0002 2 Screw, Pan Head Sltd. Locking #4-40 x .312"
24 34386.0000 1 Switch, Dispense Volume Memory
25 27443.0001 1 Decal, Fuse Rating (230V CE models only)
26 27705.0000 1 Terminal Lug (230V CE models)
01375.0000 1 Screw, Pan Head Brass #10-32 x .50"
01512.0000 1 Lockwasher, Ext.-tooth #10
27 00824.0000 1 Decal, Ground 120V
00824.0001 1 Decal, Ground 230V CE Models
28 32833.0000 1 Strain Relief, Cord (230V CE models)
01531.0000 1 Washer, Reducing
29 03290.0000 1 Cable Tie, Power Cord Retainer
30 00637.0007 1 Shield. Terminal Block
31 38894.0001 1 Switch, Master ON/OFF (Late Models)
01308.0003 2 Screw, truss Head, Locking BLK #6-32 x .25"
01327.0000 4 Screw, Pan Head #10-32 x .38"
01512.0000 4 Lockwasher #10
The following items are not illustrated
32 20630.0005 1 Power Cord (LCC-2 & LCA-2 Models only)
23799.0001 1 Power Cord (LCC-2C & LCA-2C Models only)
33 34534.0000 1 Harness, Main Wiring (Early models)
36798.0000 1 Harness, Main Wiring (Late models)
34534.0001 1 Harness, Main Wiring (230V CE Models))(Early models)
36798.0001 1 Harness, Main Wiring (230V CE Models))(Late models)
34 34535.0000 1 Harness, Switches/Power (Early models)
38570.0000 1 Harness, Switches/Power (Late models)
35 34519.0000 1 Harness, Portion Control Wiring (Early models)
36 34523.0000 1 Harness, Motors Wiring
37 34525.0000 1 Harness, T-block to Tank Heater & Limit
34525.0001 1 Harness, T-block to Tank Heater & Limit (Master ON/OFF Switch)
38 34526.0000 1 Harness, Probe Wiring (Early models)
39 34578.0000 1 Harness, Upper Fan Wiring
40 34961.0000 1 Harness, Tube Warmer Wiring (Early models)
41 21014.0196 1 Lead, Thermostat Blk 30.0" (Early models)
42 35081.0000 1 Wire, Double Limit Jumper (230V CE Models)
43 36049.0002 1 Jumper (Models with Portion Control)
44 37518.0000 1 Harness, Door Wiring (Late models)
34767 073007
Terminals
