ITEM PART NO. QTY. DESCRIPTION
7
* Indicates the part number listed is for reference only. See DESCRIPTION for possible service replacement.
HOUSING & PANELS
23 34960.0000 1 Decal, Terminal Block Wiring
34960.0000 1 Decal, Terminal Block Wiring (Models w/Master ON/OFF Switch)
24 34641.0000 1 Schematic, Electrical (LCC-2, LCA-2)
34641.0001 1 Schematic, Electrical (LCC-2A, LCA-2A)
34641.0003 1 Schematic, Electrical (LCC-2, LCA-2)(Models w/Master ON/OFF Switch)
25 34190.0000 1 Brace
01311.0003 2 Screw, Truss Head, Sltd. Blk #8-32 x .25"
26 34194.1001 1 Panel w/Decal, Upper Access (Includes item 29)
01311.0003 4 Screw, Truss Head, Sltd. Blk #8-32 x .25"
27 34281.0001 1 Cover, Top/Front (Models LCC-2 only)
34165.0003 1 Cover, Top/Front (Models LCA-2 only)
02331.0001 2 Screw, Truss Head, Sltd. Blk #10-32 x .38"
01315.0005 2 Screw, Truss Head, Sltd. Blk #8-32 x .38"
28 34189.1001 1 Cover w/Decal, Top/Rear (Includes item 29)
01315.0005 2 Screw, Truss Head, Sltd. Blk #8-32 x .38"
29 37881.0000 3 Decal, No Serviceable Parts
30 28181.0003 1 Decal, Optional Field Wiring
31 38820.0000 1 Plate, Cover (Not used on models w/Master ON/OFF Switch)
01308.0003 2 Screw, Truss Head, Locking BLK #6-32 x .25"
32 34893.0001 - Drip Tray Kit (Includes items 18 & 19)
33 11707.1000 - Hose, Silicone .25" ID x 12.0" (Use as required)
11707.1001 - Hose, Silicone .25" ID x 36.0" (Use as required)
11707.1002 - Hose, Silicone .25" ID x 120.0" (Use as required)
Not Illustrated
34767 073007
