Bunn MHG Service & Repair Manual

25
SERVICE (Cont.)
DECHAFFER (Models LPG & FPG)
FIG. 13 DECHAFFER
P1062
Location:
The dechaffer spring plates are located in the burr
housing cap.
1
FIG. 14 DECHAFFER REMOVAL/REPLACEMENT
P1063
2
Removal and Replacement: Refer to Fig. 14
1. Remove coffee beans from hopper(s).
2. Lay grinder on it’s back.
3. Remove the #4-40 truss head screw securing
dechaffer support (1) to the burr housing cap.
4. Remove dechaffer support (1).
5. Remove dechaffer spring plate (2) from burr hosing
cap.
6. For models with extra fine dechaffer, remove dechaf-
fer support (3).
7 Place new dechaffer spring plate (2) in the slot in
the burr housing cap.
8. Place dechaffer support (1) over dechaffer spring
plate (2), support (3) and secure with a #4-40 truss
head screw.
OPTONAL EXTRA
FINE DECHAFFER
3 2 1
41545 122209
